Antifungal property of essential oil extracted from Zanthoxylum armatum (Timur)

Nabina Prajapati,1 Pravin Ojha,2 Tika Bahadur Karki3

1National College of Food Science and Technology, Nepal
2Food Research Division, Nepal Agricultural Research Council, Nepal
3Department of Biotechnology, Kathmandu University, Nepal

Correspondence: Pravin Ojha, Food Research Division, Nepal Agricultural Research Council, Khumaltar, Lalitpur, Nepal, Tel +977-9851023022

Received: October 01, 2014 | Published: November 19, 2015

Citation: Prajapati N, Ojha P, Karki TB. Antifungal property of essential oil extracted from Zanthoxylum armatum (Timur). J Nutr Health Food Eng. 2015;3(1):266-270. DOI: 10.15406/jnhfe.2015.03.00096

Download PDF


The aim of this research work was to test the effect of essential oil of Zanthoxylum armatum (timur) originated from Salyan (Nepal) against five isolated fungi i.e. Aspergillus sp., Alternaria sp., Penicillium sp., Cladosporium sp. and Helminthosporium sp. The essential oil yield of sample from Salyan was 2.29%. Different concentrations i.e. 5µl, 10µl, 15µl and 20µl of essential oil were used to determine zones of inhibition. The zone of inhibition was highest against Cladosporium sp. at all concentrations, while it was lower against Penicillium and Helminthosporium sp. MIC values of essential oil of Zanthoxylum armatum were found to be 0.16mg/ml, 0.14mg/ml, 0.4mg/ml, 0.1mg/ml and 0.4mg/ml against Aspergillus sp, Alternaria sp, Penicillium sp, Cladosporium sp and Helminthoaporium sp respectively.

Keywords: Zanthoxylum armatum, minimum inhibitory concentration, zone of inhibition, anti-fungal property


Timur (Zanthoxylum armatum) is a major indigenous spice of Nepal. The ripe fruit follicles are usually reddish in color and 4 to 5mm in diameter. The dried fruit also contain an aroma that is present in brown fruit wall (pericarp-shell). It may be able to develop numbing or anesthetic feeling on the tongue. Seeds are solitary, globose, shining and have bitter taste.1 Timur is not only used as flavouring in cooking but also its seed oil and crushed seeds are added to cereal seeds and legumes to protect them against damages caused by stored grain pests.2 Timur is the main non-timber forest product of Nepal. This spice is mostly cultivated in the mid-western region of Nepal. Among 850-1100tonnes of timur harvested in Nepal, 400 tonnes of timur are collected alone in Salyan district.3

Loss of nutrient result in loss of quality, quantity and monetary value is due to toxigenic strains of mold during post-harvest storage and processing.4 Ten percentage of agricultural food commodities in the world are severely spoiled by molds to the extent that they are no fit for consumption.5 Molds like Aspergillus sp., Penicillium, Cladosporium, Alternaria, Helmenthosporium, etc produce mycotoxins among which aflatoxin was found to have carcinogenic risks. Hence, aflatoxin contamination represents a serious threat to food contamination in both developing and developed countries.6 The spoilage of foods as a result for contamination with such molds can be prevented by the use of several spices.7 The essential oil of fruits of Z. armatum exhibits good antibacterial, antifungal and anthelmintic activities.8 The largest zone of inhibition was obtained against Bacillus subtilis (23 mm) and minimum bactericidal concentration (MBC) value of 2.5mg/L was obtained.9 Essential oil of it is assessed for their fungitoxicity against Alternaria brassicicola.10

However, data are lacking regarding effectiveness of essential oil (timur) against food spoilage fungi. Thus, the aim of this study was to assess the antifungal activity of essential oil extracted from timur against several fungi. Essential oil production of timur and its utilization can add value to this indigenous spice as well.

In the present study, essential oil of timur was tested against five molds that can contaminate foods. The purpose of this was to create directly comparable, quantitative, antifungal data and to generate data for the essential oil of timur. This study suggests that the essential oil of timur has some antifungal property.

Materials and methods

Collection of timur and extraction of essential oil

The Timur (dry fruit) was collected from the local market (Asan) of Kathmandu valley, which was from the districts of mid-western regions of Nepal (Salyan) shown in Figure 1. The timur were grinded by the use of grinder to the coarse size of 75 mesh size (IS standard) and stored in an airtight containers under refrigerated condition (4°C) until use. The ground sample of timur (50g) was hydro distilled in a Clevenger apparatus for 5-6hours.11 The volatile oils were stored in sealed vials at 4°C until analysis as shown in Figure 2. The yield of the oils was calculated based on dried weight of powdered samples of Timur.

Figure 1 Dry fruits of timur.

Figure 2 Essential oil of timur.

Isolation and identification of the fungi

The fungi were isolated from soil and the spoiled meat, vegetables and fruits in media potato dextrose agar by spread plate technique at temperature 250C for 5 days. Then, the color of different shapes and colonies were further point inoculated on the plates of potato dextrose agar and again incubated at 25˚C for 5days.12 The isolated fungi were then microscopically examined and the fungi were identified in accordance with Benson.13

Determination of zones of inhibition

A sterile wire loop was used to place the test fungi into a test tube with sterile water over an open flame to obtain fungal suspension in the sterile water.14 The prepared inoculums of fungi were swabbed all over the surface of the PDA plate using sterile cotton swab. Two wells of 6mm diameter were bored in the medium with the help of sterile cork-borer having 6mm diameter and were labelled properly. The essential oil of timur sample was filled in one of the wells with the help of micropipette. Different doses of the essential oil were used i.e. 5µL, 10µL, 15µL and 20µL for the test against each fungi. The next well was filled with same volume of the sterile water as the negative control. Plates were left for some time until the essential oil diffused in the medium with the lid closed and then, incubated at 25°C for 5days. The zone of inhibition was measured by using scale ruler and means were recorded after incubation.9

Determination of minimum inhibitory concentration (MIC)

0.01 to 20mg/mL of the essential oil was prepared by using 100% dimethyl sulfoxide (DMSO).The prepared essential oil ranging from 0.01 to 20mg/mL were added to the well of each petri dish along with DMSO, as control. Further, it was incubated at 25°C for 5days and then, inhibition of the growth organism was observed and MIC was determined.15

Statistical analysis: All the data obtained in this experiment were analyzed by statistical program Genstat release 7.22, VSN International Ltd. Sample means were compared by LSD method at 95% level of significance.

Results and discussion

Yield of essential oil

The essential oil of the samples of timur extracted by the hydro-distillation method was light yellow in color. Essential oil yield for the timur of Salyan was found to be 2.29±0.05%. The findings were greater than that of Tiwary et al.,2 and Prakash et al.,16 but less than that of Verma and Khosa.17 The difference might be due to differences in timur variety.

Isolation and identification of fungi

Different spoiled food materials and soil were used for the isolation of fungi. Five different strains of fungi namely Aspergillus sp., Penicillium sp., Alternaria sp., Cladosporium Sp. and Helminthosporium sp. as shown in Figures 3‒7 respectively were isolated from these and their morphological characteristics were illustrated in Table 1.

Figure 3 Aspergilus sp. on PDA plate.

Figure 4 Penicillium sp. on PDA plate.

Figure 5 Alternaria sp. on PDA plate.

Figure 6 Cladosporium sp. on PDA plate.

Figure 7 Helminthosporium sp. on PDA plate.


Morphological Characteristics

Aspergillus sp.

Grayish black in color; reverse side white to yellow; cottony in texture; hyphae branched like fan or tree, rough irregular conidia surface

Penicillium sp.

Bluish green in color; reverse side yellow in color; Velvety in texture; brush arrangement of philaspores.

Alternaria sp.

Gray green in color at center; cottony in texture; chains of microconidia

Cladosporium sp.

Olive-gray in color; reverse side gray to black in color; Dark blast conidia different in shape.

Helminthosporium sp.

Black surface with grayish periphery; macroconidia shown.

Table 1 Morphological Characteristics of isolated fungi

Zones of inhibition

Essential oil extracted from different samples of Zanthoxylum armatum were tested separately against all five microorganisms. In every test it was clear that the essential oil showed highest inhibition against Cladosporium sp at all the concentrations and comparatively lower against penicillium sp and Helminthosporium sp as shown in Figure 8. The result show that with increase in concentration, the zone of inhibition for all species increases.

Figure 8 Effect of concentration of essential oil on isolated fungi species.

Nanasombat and Wimuttigosol18 found that essential oil extracted from fruit of Zanthoxylum limonella (Rutaceae) at concentration of 10µl/disc show zone of inhibition of 42.3, 34.0, 33.3, 25.8 and 23.5mm against Rhodotorula glutinis, Schizosaccharomyces pombe, Hanseniaspora uvarum, Aspergillus ochraceus and Fusarium moniliforme respectively. The result was different from that for Aspergillus, which may be due to difference in variety.

According to Prakash et al.,16 the essential oil of another variety of Zanthoxylum i.e. Zanthoxylum alatum exhibit a broad range of antifungal activity against mold like Aspergillus flavus, niger, terreus, candidus, sydowi, fumigates, Alternaria alternate, Cladosporium cladosporioides, Curvular ialunata, Fusarium nivale, Penicillium italicum and Trichoderma virdie. By the chromatographic method against Alternaria alternate, Zanthoxylum alatum showed the zone of inhibition (RF of 0.51) of 18mm diameter.19

Tiwary et al.,2 found linalool (57%) and limonene (19.8%) as major component of essential oil of Zanthoxylum armatum. The antifungal activity of essential oil is generally due to linalool content.20 Limonene, however show effective antimicrobial activity but possess moderate antimicrobial activity.21

Minimum inhibitory concentration (MIC)

The MIC value of essential oil of Zanthoxylum armatum for Aspergillus sp was0.16 mg/mL. For Alternaria sp., it was 0.14mg/mL; while MIC value for Penicillium sp. and Helminthosporium sp. was same i.e. 0.4mg/mL. Similarly, MIC value for Cladosporium sp. was found to be 0.1 mg/mL. The MIC value for the Cladosporium sp. was the lowest and for the Penicillium sp. and Helminthosporium sp., it was highest among the test fungi as shown in Table 2.

Test fungi

Minimum Inhibitory Concentration (mg/ml)

Aspergillus sp.


Alternaria sp.


Penicillium sp.


Cladosporium sp.


Helminthosporium sp.


Table 2 MIC value required by the Zanthoxylum oil to inhibit the test fungi

Nanasombat and Wimuttigosol18 reported MIC value 1mg/mL for Aspergillus ochraceus and Fusarium moniliforme against essential oil extracted from fruit of Zanthoxylum limonella (Rutaceae). Yang and Chen22 reported MIC values of 25 and 6.25µg/ml for Cladosporium cucumerinum and Pyriculeri aoryzae against dictamnine extracted from steam of Zanthoxylum nitidum. EOs rich in oxygenated monoterpenes have been shown to possess antifungal activities19 and the essential oil of Zanthoxylum armatum is rich in oxygenated monoterpenes (75%).2 Many researchers have investigated the antifungal and antibacterial activities of individual chemical constituents of the EOs such as β-caryophyllene, caryophyllene oxide, and linalool etc;23,24 and Zanthoxylum contains high amount of linalool.16


The essential oil of Zanthoxylum armatum shows antifungal property against various fungi like Aspergillus sp., Alternaria sp., Cladosporium sp., Penicillium sp. and Helminthosporium sp. Among the test fungi, it was most effective against Cladosporium sp. and comparatively less effective against Penicillium and Helminthosporium sp. As Timur has antifungal property, it can be used as preservative in food commodities to prevent fungal growth. Further, synergistic effect of timur oil with other spices oil can be studied.



Conflict of interest

Author declares that there is no conflict of interest.


  1. Brijwal L, Pandey A, Tamta S. An overview on phytomedicinal approaches of Zanthoxylum armatum An important magical medicinal plant. J Med Plants Res. 2013;7(8):366‒370.
  2. Tiwary M, Naik SN, Tewary DK, et al. Chemical composition and larvicidal activities of the essential oil of Zanthoxylum armatum DC (Rutaceae) against three mosquito vectors. J Vect Borne Dis. 2007;44(3):198‒204.
  3. Acharya RP. Report on Market Study of Seven MAPs in Far and Mid Western Dev. Region. 2011.
  4. Bata A, Lasztity R. Detoxification of mycotoxin-contaminated food and feed by microorganisms. Trends in Food Science and Technology. 1999;10(6‒7):223‒228.
  5. Set E, Erekmen O. The afflatoxin contamination of ground red pepper and pista-chio nuts sold in Turkey. Food chem toxic. 2010;48(8‒9):2532‒2537.
  6. Wagacha JM, Muthomi JW. Mycotoxin problem in Africa: current status, implications to food safety and health and possible management strategies. Int J Food Microbiol. 2008;124(1):1‒12.
  7. Pandey B Sharma B, Khan S. Indian spices and its antifungal activity. Int J Res Eng Tech. 2013;2(12):155‒160.
  8. Mehta MB, Kharya MD, Srivastav R, et al. Antimicrobial and anthelmintic activities of the essential oil of Zanthoxylum alatum. Roxb Ind Perf. 1981;25(2):19‒21.
  9. Joshi B, Lekhak S, Sharma A. Antibacterial Property of Different Medicinal Plants: Ocimum sanctum, Cinnamomum zeylanicum, Xanthoxylum armatum and Origanum majorana. J Sci Eng Technol. 2009;5(I):143‒150.
  10. Parajuli, RR, Tiwari, RD, Chaudhary, RP, et al. Fungitoxicity of the essential oils of some aromatic plants of manging against Alternaria abrassiciocla. Sci world. 2005;3(3):39‒43.
  11. Official Methods of Analysis. 18th ed. Association of Official Analytical Chemists; 2005.
  12. Ibrahim S, Rahma MA. Isolation and identification of fungi associated with date fruits (phoenix dactylifera, linn) sold at Bayero University, Kango, Nigeria. Bayero J Pure and Applied Sci. 2009;2(2):127‒130.
  13. Benson HJ. Microbiological Applications; a Laboratory Manual in General Microbiology. 6th ed. USA: Dubuque IA. Wm. C. Brown; 1994.
  14. Ahmad S, Ali A, Beg H, et al. Ethnobotanical studies on some medicinal plants of Booni valley, District Chitral, Pakistan. Pak J Weed Sci Res. 2006;12(3):183‒190.
  15. Mahalingam R, Ambikapathy V, Panneerselvam A. Studies on antifungal activities of some medicinal plants against Ceratocystis paradoxa causing pineapple disease. World J Sci and Technol. 2011;1(7):10‒13.
  16. Prakash B, Singh P, Mishra PK, et al. Safety assessment of Zanthoxylum alatum Roxb. essential oil, its antifungal, antiaflatoxin, antioxidant activity and efficacy as antimicrobial in preservation of Piper nigrum fruits. Int J Food Microbiol. 2012;153(1‒2):183‒191.
  17. Verma N, Khosa RL. Heptaprotective activity of leaves of Zanthoxylum armatum DC in CCl4 induces heptatoxicity in rats. Indian J Biochem Biophy. 2010;47(2):124‒127.
  18. Nanasombat S, Wimuttigosol P. Antimicrobial and antioxidant activity of spice essential oils. Food Sci Biotechnol. 2011;20(1):45‒53.
  19. Guleria S, Tiku AK, Koul A, et al. Antioxidant and antimicrobial properties of the essential oil and extracts of Zanthoxylum alatum grown in North-Western Himalaya. The Sci World J. 2013:1‒9.
  20. Soares BV, Morais SM, dos Santos Fontenelle RO, et al. Antifungal Activity, Toxicity and Chemical Composition of the Essential Oil of Coriandrum sativum Fruits. Molecules. 2012;17(7):8439‒8448.
  21. Rancicl A, Sokovic M, Griensven LV, et al. Antimicrobial activity of limonene. Lek Sirov. 2003;23(23):83‒88.
  22. Yang G, Chen D. Alkaloids from the roots of Zanthoxylum nitidum and their antiviral and antifungal effects. Chem Biodivers. 2008;5(9):1718‒1722.
  23. Bougatsos C, Ngassapa O, Runyoro DK, et al. Chemical composition and in vitro antimicrobial activity of the essential oils of two Helichrysum species from Tanzania. Z Naturforsch C. 2004;59(5‒6):368‒372.
  24. Cha JD, Jung EK, Kil BS, et al. Chemical composition and antibacterial activity of essential oil from Artimisia feddei. J Micrbiol Biotechnol. 2007;17(12):2061‒2065.
