Treatment of an uncommon case of recurrent cervical spine aneurismal bone cyst, using radiotherapy: a case report

doi:10.15406/jcpcr.2016.05.00149

Journal of

eISSN: 2373-633X

Cancer Prevention & Current Research

Case Report Volume 5 Issue 1

Treatment of an uncommon case of recurrent cervical spine aneurismal bone cyst, using radiotherapy: a case report

Sasan Razmjoo, Maedeh Berahman, Somaye Barihi, Shole Arvandi, Hojjatollah Shahbazian, Seyed Mohammad Hosseini, Maryam Feli

Verify Captcha

Regret for the inconvenience: we are taking measures to prevent fraudulent form submissions by extractors and page crawlers. Please type the correct Captcha word to see email ID.

Department of Radiotherapy and Oncology, Ahvaz Jundishapur University of Medical Sciences, Iran

Correspondence: Maryam Feli, Department of Radiotherapy and Oncology, Ahvaz Jundishapur University of Medical Sciences, Golestan Boulevard, Ahvaz, Iran, Tel 9.86134E+11, Fax 9.86134E+11

Received: January 01, 1971 | Published: June 14, 2016

Citation: Razmjoo S, Berahman M, Barihi S, et al. Treatment of an uncommon case of recurrent cervical spine aneurismal bone cyst, using radiotherapy: a case report. J Cancer Prev Curr Res. 2016;5(1):209-211. DOI: 10.15406/jcpcr.2016.05.00149

Download PDF

Abstract

Aneurismal bone cysts are uncommon in spines, constitute of only 15% of all spine bone tumors. They occurs the most common in the thoracic spine and the least in the cervical ones. Although the mainstay of the treatment is surgery, but the management of recurrent cases especially in the cervical spine is challenging, as a result of complicated surgery in this area. The present case provides information regarding treatment of a recurrent cervical spine ABC, using radiotherapy.

Keywords: aneurismal bone cyst, radiotherapy,spine bone tumor

Introduction

Aneurismal bone cysts (ABC) constitute of 1-2.5% of primary bone tumors, despite their benign nature, they can be locally aggressive and expanding.¹ Most of the cases occur in the first and second decade of life, with the mean age of 14 to 16 years at diagnosis. These highly vascular, relatively rare lesions mostly affect long bones followed by spines with slightly female predominance. The lumbar spine is the most frequent site, followed by thoracic, cervical and sacral ones.²

The most common feature of ABC is local pain, which could be associated with a palpable tender mass. Neurologic involvement is not common, but progression of the disease could lead to paraplegia and cord compression.^3,4

Treatment options include curettage, subtotal or total resection with or without reconstruction, schlerotherapy and radiotherapy. Despite all these treatments recurrences particularly after subtotal resection is not uncommon. Treatment of recurrent spine ABC is a clinical challenge and could result in serious complications.^5,6

In this article we present an uncommon case of recurrent multilevel aneurismal bone cyst of cervical spine.

Case presentation

A 23 years old lady was referred to our clinical oncology department with a history of neck mass. Her symptoms back to over one year ago with a large, non-tender, firm, gradually progressive swelling over the right side of her neck. The pain was constant which radiating to shoulder. She had developed upper extremity weakness through months. She had no history of trauma or co morbid condition. Her general physical examination was normal. Neurological examination revealed decreased upper limb muscle force by the score of 2/5.

Her neck ultrasound showed a thick irregular wall hypoechoeic soft tissue mass 24x20 mm size in right cervical portion with cystic change and internal echo. Computed tomogram of spine showed 35x30 mm heterogeneous enhancing mass in right para vertebral area, extending into right C5-C6 foramina. Craniospinal magnetic resonance imaging showed a heterogeneous mass lesion 35x35x45mm size in right side of neck at level of C5-C6 with extension into right side neural foramen, which caused expansion without destruction. Mentioned mass showed cystic component (Figure 1).

Figure 1 Pre-operation MRI.

Radical resection of tumor, foramenectomy of C5-C6 and resection of tumor, as well as, C3-C4-C5-C6 posterior arthrodesis with lateral mass screw and posterolateral fusion with all grafting was done.

In the postoperative period, her recovery was uneventful. Microscopic examination showed blood filled spaces which lined by spindle-shaped cells admixed with osteocalst-type giant cells, set in vascularized mildly inflamed fibrotic stroma. Multiple fibrous septa which displayed areas of new bone formation were identified. These pathologic findings were compatible with ABC.

Two months later she was re-admitted with a painful recurrent mass measuring 35x20mm at the same location (Figure 2). She underwent curettage, and referred for radiotherapy one week later. She received external beam radiotherapy using a 6 megavoltage photon beam on a linear accelerator, with two parallel-opposed lateral rectangular field size of 8.5x7 cm (length x width ). In a continuous course, she treated 5 days a week with standard daily fractions of 2Gy up to a total dose of 26Gy.

Figure 2 External beam radiotherapy.

She had complete relief of her symptoms within 2 weeks of completing radiotherapy. On her last visit, 36 months after radiotherapy, she was symptom free and computed tomogram of neck after 36 months showed no evidence of recurrence (Figure 3).

Figure 3 Post operation CT scan after 36 months follow up.

Discussion

Aneurysmal Bone Cysts compromise of approximately 15% of primary spine tumors, which more affect the lumbar and thoracic spines than cervical ones. Cervical ABCs account for 5% of all spine ABCs. Spine ABCs affect posterior elements and the pedicle more than anterior elements and the lesion usually involve only one level, but multilevel cases have been reported as well.⁷ In almost 30% of patients, the tumour intersects to the adjacent vertebrae through surrounding soft tissue mass.^3,4

Our patient presented as a tender lump on the anterior right side of her neck and after evaluations diagnosed as multilevel cervical ABC.

The accurate pathogenesis of the disease is not well known. Some theories suggested these lesions are preceded by traumatic fracture, subperiosteal hematoma or pre-existing bone diseases, including fibrous dysplasia, giant cell tumor and non-ossifying fibroma.^1,8 As mentioned above, in this case there was no history of trauma or previous bone disease.

Microscopic pathological findings of ABC show numerous cavernous blood filled cavities separated by fibrous septa. These cavities are not true vascular channels, since they lack lining by endothelium.^1,9 As it seen in the present case osteoclast-type giant cells in fibrotic stroma and new bone formation, would be found on microscopic specimen.

Preoperative CT scan is reliable for detecting the bone destruction and the integrity of cortical bone. Besides, it is useful for surgical planning and instrumented fusion based on the tumour size and extent. The MR imaging modality is better evaluating the full extent of bone and soft tissue involvement and degree of neural element compression. In addition, it would show the characteristic appearance of cysts containing fluid-fluid interfaces on T2-weighted MR imaging.

In the present case both MR and CT was prior to surgery.^2,10 While ABCs are benign, non-neoplastic phenomena, their rapid growth could result in extensive bone destruction and neurologic involvement. Consequently, the aggressive therapy is crucial.

The optimal treatment of spine ABC is still controversial.⁶ Because of the unique anatomy and function of spines, surgical accessibility is complicated.

Despite the fact that complete resection and reconstruction is the treatment of choice in ABC, recurrence would occur even after such an extensive operation. Management of the recurrent ABC in cervical spine could be challenging, since re-resection would result in severe blood loss, spine instability, neurologic complication, and even paralysis.

Since adequate surgical resection of recurrent cervical spine ABC would result in significant morbidity or poor cosmetic outcome, alternatively radiotherapy can be used.

Feigenberg et al.¹¹ used megavoltage radiotherapy, using the prescribed dose of 26-30 Gy, for the local treatment of spine ABC in 19 cases. They revealed that modern-day RT could play a role in the treatment of recurrent or inoperable spine ABC with minimum toxicity. Besides, it is useful in pain relief of such patients. They followed patients at the minimum of 20 months and did not detect any sign of complication or recurrence.¹¹ In 2006 Kumar et al.¹² reported a case of recurrent ABC on temporal bone, which were treated with 31.5 Gy in 18 fractions and found reasonable outcome.¹² Zhu et al.¹³ evaluated the long-term effectiveness of RT as an adjuvant or alternative treatment for ABC. They reviewed the medical records of 12 patients who received RT at the mean dose of 30.15 Gy and followed them at least 3 years. No patient showed RT complications or recurrence.¹³

According to previous reports we successfully treated a recurrent cervical spine ABC after subtotal resection, using RT as an adjuvant, since the total resection wasn’t possible and the rate of second recurrence was high. She remained recurrence and symptom-free 36 months after the end of treatment.

More investigations are required to evaluate the role of radiotherapy as an adjuvant treatment modality after subtotal resection or curettage of spine ABC, which could decrease the subsequent recurrences and re-resection morbidity.
