Goldenhar-Gorlin syndrome or Oculo-auriculo-vertebral dysplasia is a congenital condition with abnormalities of head and bones of spinal column. It results from abnormal morphogenesis of first and second branchial arches, resulting in disruption of normal facial development. We report a case of Goldenhar Syndrome admitted in our unit but with a rare association of postaxial polydactyly. Though Goldenhar syndrome is not rare, the unusual presence of postaxial polydactyly prompted us to report this case.

Keywords: goldenhar syndrome, hemi-facial microsomia, oculo-auriculo-vertebral spectrum, polydactyly, situs inversus

Goldenhar-Gorlin syndrome or First and Second Branchial Arch syndrome or Oculo-auriculo-vertebral dysplasia is a congenital condition with abnormalities of head and bones of spinal column. It results from abnormal morphogenesis of first and second branchial arches, resulting in disruption of normal facial development.¹ When the movement and development of these tissues is disrupted, the face may have abnormal openings, underdevelopment and excess skin. It was first described by Dr. Maurice Goldenhar in 1952.² Incidence is one in 3000-5000 live births with male predominance.³ Sporadic in most of the cases. However, 1-2% of cases occur in families with autosomal dominant transmission. Prognosis is good.

We report a case of full term, appropriate for gestational age, male baby born at 38 weeks out of non-consanguineous marriage to 27 year old primi mother with a married life of 15 years. Mother is seropositive for retro-viral disease which was diagnosed antenatally. The baby was admitted due to dysmorphic appearance on day 1 of life. There were no h/o congenital malformations in any of the family members. No h/o exposure to radiation or drugs during pregnancy. No history suggestive of use of medications for fertility. Baby was conscious and alert. His vital parameters were within normal limits.

General examination

1. Facial asymmetry involving left temporal, maxillary and mandibular regions (Figure 1).
2. Low set ears with microtia left side, meatal stenosis and five pre-auricular skin tags (Figure 2).
3. Ocular hypotelorism (canthal index< 0.32) with a canthal index of 0.27 and left micropthalmia (Figure 3).
4. Macrostomia and high arched palate.
5. Short neck (neck length: length ratio = 1:15 normal being 1:13), webbing of neck and low posterior hair line (Figure 4).
6. Unilateral left upper limb post axial polydactyly (Figure 5).
7. Right undescended testis.
8. Anthropometry: Microcephaly (HC < 3rd centile for boys at birth) and short trunk (US: LS ratio=1.5:1).

Figure 1 Facial asymmetery with macrostomia.

Figure 2 Preauricular skin tags.

Figure 3 Occular hypotelorism and left microphthalmia.

Figure 4 Webbing of the neck.

Figure 5 Left upperlimb postaxial polydactyly.

Systemic Examination

Respiratory system, Abdomen, Neurological examination was normal.

Cardiovascular system: Heart sounds better heard on the right side.
Fundus: Normal.

1. X-ray erect abdomen including chest showed situs in versus totalis (Figure 6).
2. X-ray cervical spine AP and Lateral views showed cervical hemivertibrae (Figure 7).
3. Ultrasound abdomen showed normal study.
4. CT scan brain plain showed normal study.
5. 2D Echocardiogram showed
1. Situs in versus with dextrocardia.
2. Large ASD with L-R shunt.
3. Tiny apical muscular VSD with L-R shunt.
4. Dilated coronary sinus.
5. Right aortic arch.
6. Normal valves and biventricular function.

Figure 6 Xray chest with abdomen showing situs inversus totalis.

Figure 7 Cervival hemivertebrae.

The baby was diagnosed as a case of Goldenhar syndrome based on the clinical features and investigations. Baby was started on nevirapine prophylaxis. Formula feeds were started with paladai after consent from the parents. Mother was taught feeding and handling of the baby. Baby was discharged home on day 5 of life. Baby was readmitted on day 15 of life with lethargy, poor feeding and abdominal distension. Clinical examination and laboratory investigations were suggestive of late onset sepsis. Baby was ventilated and died on day 18 of life.

Oculo-auriculo-vertebral (OAV) spectrum is often used synonymously with Goldenhar syndrome and hemi-facial microsomia (HFM). But it refers to 3 rare disorders representing the range of severity of the same disorder

1. OAV disorder–mildest form.
2. Hemi facial microsomia- intermediate form.
3. Goldenhar syndrome–most severe form.

Goldenhar syndrome is a multi-organ involvement with varied clinical features.

Major components

1. Hemi facial microsomia.⁵
2. Ocular anomalies–Inferio-temporal epibulbar dermoids (75%),^6-8 Lipodermoids (50%)^6-8     Upper eyelid coloboma, Micropthalmia, Hypotelorism, Blepharophimosis, Strabismus⁹
3. Vertebral anomalies¹⁰–Scoliosis (50%), Cervical hemi vertebrae (30%) Spina bifida.

Minor components

1. Auricular¹¹: Anotia or microtia

 Meatal stenosis, Pre-auricular skin tags, Conductive hearing loss, Low set ears

2. Cranio-facial defects: Cleft lip and palate (10%),¹² Macrostomia¹³
3. Congenital heart defects–5-58% cases¹⁴

 32%-VSD, TOF and ASD
39%-Conotruncal defects
14%-Targeted growth defects
07%-Situs and looping defects
04%-PDA and Left sided obstructive lesion

4. Gastrointestinal system¹⁶–Tracheo-esophageal fistula, Umbilical and inguinal hernias
5. Genito-urinary anomalies¹⁷–Renal ectopia, Hydronephrosis, Undescended testes Chordae
6. Others–Abnormal ribs, CTEV, Short neck, Webbing of neck, Low posterior hair line, Sprengel’s deformity

Our case shows most of the manifestations of Goldenhar syndrome with a rare association of unilateral left upper limb post axial polydactyly and situs inversus totalis which prompted to report this case. Another interesting point is the presence of HIV infection in the mother. It is not known whether HIV infection can cause congenital malformations like this. The care of the baby from diagnosis to follow up has been summarized in Figure 8 Flow diagram (CARE Guidelines). We have done literature search and found out the previous cases reported in Table 1. Polydactyly has been reported previously as rare association but situs inversus is never reported till date in goldenhar syndrome.
