Research Article Volume 2 Issue 5
1Vimix Solutions Private Limited, India
2Department of Forest Pathology, Forest Research Institute, India
3Department of Basic Sciences, Collage of Forestry (VCSG Uttarakhand University of Horticulture & Forestry), India
4Department of Soil Science, College of Agriculture, G. B. Pant University of Agriculture & Technology, India
Correspondence: Solomon Das, Vimix Solutions Private Limited, Danda Lakhond, Sahastradhara Road, Dehradun 248001,India, Tel 9197 6003 6146,
Received: August 02, 2018 | Published: September 28, 2018
Citation: Das S, Singh YP, Yogesh KN, et al. Effect of fluorescent pseudomonas and Glomus sp. on the bamboo root morphology. Forest Res Eng Int J. 2018;2(5):250-261. DOI: 10.15406/freij.2018.02.00058
Dendrocalamus strictus (male bamboo) is one of the most important bamboo species in India. The bamboo plays an important role in various areas, such as socio–economy of the country as well as the environment. As it also the fastest growing giant grass in tropical region, especially during the monsoon season, gathering of biomass at such quick time is also remains a mystery. Bamboo has a very shallow root system (upto 3–4 feet) with fibrous in nature, the dependency of roots on surrounding microbes for nutrient uptake needs an attention. In the current study, researchers attempted to explore the role of rhizospheric microbes isolated from the roots of such bamboos from the forest on the root architecture of bamboo roots. It was found that fluorescent pseudomonads and arbuscular mycorrhizae played a definite role in shaping the root morphology, which indirectly or directly influenced in gathering biomass in the plants more quickly, especially in case of bamboo.
Keywords: rhizosphere, PGPR, mycorrhizae, bamboo, P solubilisation
India is one of the 12 mega diversity countries of the world which has 7% of the world’s biodiversity and total forest cover of 21.05% (692,027 km2) of the geographical area of the country.1 India is the second richest country in the world after China in terms of bamboo genetic resources. Indian bamboo forests contain 23 genera including 19 indigenous; and 136 species with 125 indigenous and 11 exotic.1 The bamboo is also called ‘green gold’ in India; the country that has the second–largest reserve of bamboo in the world.2 Bamboo in many ways is the mainstay of the rural Indian economy, sparking considerable social and ecological spin–offs. Among the bamboo species, Dendrocalamus strictus (Roxb.) Nees (English name=male bamboo) is an important bamboo species in India.3
The root system of D. strictus consist of a dense mass of short rhizome in which nodes are close to each other and provided with the clusters of small rootlets. Every node may have one or more eyes, which are capable of developing into new culm, even though, they, generally, remain dormant. The new rhizome grows horizontally for a short distance and, then, turns upwards, generally producing new culms in the same year. If the old rhizome die and rot, the new rhizomes grow towards the center. The root system of D. strictus is superficial and does not grow to more than a meter deep. The culms are prone to uprooting by strong winds. Due to the superficial root system, changes in soil moisture have marked effect on the growth, and young plantation of bamboo is likely to be adversely affected during spells of prolonged drought.4
Bhattacharya et al.5 studied the relevance of mycorrhiza for bamboo cultivation in laterite wastelands along with mycorrhizal dependency and phosphorous utilisation efficiency. The solubilisation of phosphate is reported to be the common mode of action for PGPR and studies by Singh and Kapoor6. They showed that PSB such as B. circulans together with arbuscular mycorrhizal (AM) fungi increased plant yield and P uptake of wheat. Phosphate solubilising bacteria (PSB) have great prospects to improve plant growth under phosphate deficient soils when used in conjunction with AM fungi.7 They are known to mobilise phosphate ions from sparingly soluble organic and inorganic phosphate sources. However, the released phosphate does not reach the root surface as a result of inadequate diffusion.8,9 It was proposed that AM fungi could improve the uptake of the solubilised phosphate, hence, this combined interaction should improve phosphate nutrition and supply to plants.10 Muthukumar and Udaiyan3 studied the effect of inoculation of arbuscular mycorrhizzal fungi and PGPR on the growth of bamboo (D. strictus) in different tropical soils. They observed that combined inoculation of AM fungi, phosphate solubilising bacteria (PSB) and A. brasilense resulted in maximum growth response under both fertilised and unfertilised conditions and soil types (alfisol & vertisol).
In the current study, researchers attempted to find the effect of AM fungi and selected fluorescent pseudomonads on the root architecture of D. strictus. The role of rhizospheric microbes around root system of D. strictus on the root architecture, which influence the nutrient uptake is studied in the present research.
Isolation of fluorescent pseudomonads and arbuscular mycorrhizae from the rhizospheres of D. strictus
The study area included three locations: first, reserve forest of the FRI, Dehradun, which lies between the latitudes of 30° 20'N and longitudes of 78° 00'E; second, Shivpuri near Byasi (Rishikesh), which lies between latitudes of 30° 06'N and longitude of 78° 25'E; and third, Chiriapur range (Haridwar district), which lies between the latitude of 29° 52'N and longitude of 78° 11'E. These locations were selected based on the presence of different growth forms of D. strictus.11 Fluorescent pseudomonads and arbuscular mycorrhizae were isolated from the roots of these different growth forms and were selected in–vitro based on their growth and biocontrol efficiency.
In–vivo Selection of fluorescent pseudomonads based on root colonisation, growth and proliferation of D. strictus
The host
As a host, D. strictus seedlings were used for the study. These seedlings were raised from seeds collected from Nahan (Paonta Sahib, H.P.) forest range. The seeds were surface sterilised using 0.5% NaOCl and rinsed 5–6 times by sterilised distilled water. Once washed, these seeds were soaked overnight in sterilised distilled water. Next day, D. strictus seeds were sowed in sterile soil (pots) and kept in humid and warm place for germination. After 15–20 days, 3–5 leaves stage seedlings were used for the experiment. The seedlings were raised in two types of soils. First, of sterilised soil and other sterilised soil inoculated with culture of mycorrhizal fungus, Glomus etunicatum.
The soil
Mixture of sand: soil: farm yard manure (FYM) was used in the 2:1:2 % ratio. Potting mixture was used having the physico–chemical characteristics of the experimental soil (Table1).
pH |
Organic matter |
Organic carbon |
Available |
Available |
Available |
7.9 |
1.99 |
1.16 |
301.5 |
19.5 |
345 |
Table 1 Physico–chemical characteristics of experimental soil
Container
The seedlings were raised in mud pots of about 5 kg capacity. Roughly 150 seedlings were maintained in each pot. These seedlings once raised were transferred to root trainers of 25 cups of 150 ml capacity. After these seedlings achieved the height of 4–5 cm, they were transferred to root trainers of 12 cups of 300 ml capacity.
Preparation of microbial inoculum
Thirty bacterial isolates (10 for each location) were screened out from total 90 biochemically characterised fluorescent pseudomonads. This selection was again based on the functional (growth & biocontrol) attributes of bacterial populations. The quantity estimation of in–vitro P solubilisation was conducted using NBRIP media based on method given by Nautiyal12.
Bacteria were grown on King's B broth for 3 d at 27°C. The bacterial suspension was centrifuged at 2,000 g for 15 min, the supernatant was discarded, and the pellet was re–suspended in 0.1 M hydrated magnesium sulphate (MgSO4.7H2O). The suspension was centrifuged and re–suspended two more times. The optical density of the bacterial suspension was measured at 640 nm on a spectrophotometer, and was adjusted to 0.6 absorbance units, which correspond to approximately 1x109cells/ml. Root dip method was used. D. strictus seedlings roots were surface sterilised in 0.05% NaClO solution for 30 seconds and rinsed six times in sterilised water. After, these seedlings were dipped into bacterial suspension (109/ml) for 20min and planted.
Treatment
The experiment was carried out in sterilised as well as unsterilised soil condition with uninoculated control (T1).
Plants were inoculated with seven fluorescent pseudomonads isolates. Each bacterial isolate was taken as a single treatment, such as, PFF1, PFF3, PFF13, PFC31, PFC71, PFC72 and PFC 125. As per experiment conducted in the nursery, the most efficient P. fluorescens (PFC 125) was used for inoculation in the study.
Replication
In all, 8 replicates were maintained in each treatment.
Duration and evaluation of the experiment
The root colonisation and proliferation of D. strictus were evaluated at the end of 42 days after the transplantation of the seedlings into the root trainers. The 42 days were decided due to the average time taken for arbuscualar mycrorrhizae to establish in the roots of bamboo.
Observation
Observations on different plant parameters were taken weekly for six weeks. Plant height was taken in centimeters (cm) by measuring scale. The shoots were included in counting the tiller number. Collar diameter was taken in mm from shoot’s initiating point at soil level with the help of electronic digital Vernier Calipers (NSK MAX–Series, Micrometer Mfg. Co. Ltd., Japan). The roots were washed with tap water to remove adhering soil particles and excess water was removed with the help of blotter paper. The root and rhizome volume was determined by the water displacement method in a graduated cylinder.13 Excluding old ones, all other rhizomes were numbered. After uprooting plants from root trainers, their shoot and root portions were washed, cut and dried by placing them between the folds of blotter paper. Then, plants were kept in an oven at 60°C till their weight (g) measured constantly.
Evaluation of bacterial population on the roots of bamboo seedlings
Roughly 1 cm long freshly uprooted roots were carefully, randomly cut from each plant. Some of the rhizospheric soil was also collected in plastic bags. It was made sure that the roots were not washed for this step. The roots and soil were kept in 5° to 10°C to maintain their moisture and microbial activity until the study was completed. Combining roots and rhizospheric soil, 1g of sample was serially diluted up to 10-5. Now from dilutions 10-3 to 10-5, 100µl sample was spread on a plate with King’s B media and incubated at 28°C for 2 days. Under the colony counter or UV lamp, the fluorescent colonies were counted. Once the colonies are counted, the log CFU (colony forming unit) was estimated using following formula:
For example, for the 1x 10-8 dilution plate, 0.1 ml of the diluted cell suspension was plated that counted 200 CFU, then the calculation would be:
The endophyte
The myorrhizzal culture of G. etunicatum Backer & Gerdemann was borrowed from G.B. Pant University of Agriculture & Technology, Pantnagar, Uttarakhand. The culture was mass multiplied in pot (sterilised sand) having maize plants. The seedlings were raised in a potting mixture containing one part of inoculum (having root bits, mycelium and spores) mixed with 9 parts of a sterilised potting mixture. The root colonisation and spore number were estimated before the inoculation. After 40 days in earthen pots, the seedlings are transferred into root trainers.
Root architecture
The effect of different treatments on the root architecture is registered (Figures 1–4).
Figure 1 Effect of different treatments on growth and proliferation of D. strictus seedlings raised in unsterilised soil.
Figure 2 Effect of different treatments on growth and proliferation of D. strictus seedlings raised in sterilised soil.
Figure 3 Effect of different treatments on root of D. strictus seedlings raised in unsterilised soil.
Average root volume
Irrespective of soil conditions, the controls registered minimum and significantly lower root volume than treated plants (1.04 cc; Table 2). The seedlings treated with combination of G. etunicatum, PFC125 and standard dose of NPK (T11: 1.93 cc) registered maximum volume, which was at par with plants treated in combination of G. etunicatum and standard dose of NPK (T7:1.79 cc), PFC125 and standard dose of NPK (T9: 1.78 cc) and PFC125 and half dose of NPK (T10:1.75 cc). Irrespective of treatments, no significant difference in root volume was registered in seedlings raised in unsterilised and sterilised soils.
Treatment |
Soil condition/ Av. root vol. (cc) |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
1.17(20.5)* |
0.91(10.3) |
1.04 |
Glomus etunicatum (G.E.; T2) |
1.13(17.6) |
1.56(40.3) |
1.35 |
Pseudomonas fluorescens (PFC125; T3) |
1.55(37.2) |
1.74(65.1) |
1.64 |
Std. NPK (T4) |
1.47(35.7) |
1.61(49.3) |
1.54 |
½ NPK (T5) |
1.73(67.6) |
1.72(54.3) |
1.72 |
G.E + PFC125 (T6) |
1.65(52.9) |
1.45(29.7) |
1.55 |
G.E + Std. NPK (T7) |
1.84(119.8) |
1.74(59.1) |
1.79 |
G.E + ½ NPK (T8) |
1.52(37.0) |
1.65(47.1) |
1.59 |
PFC125 + Std. NPK (T9) |
1.88(77.7) |
1.68(49.7) |
1.78 |
PFC125 + ½ NPK (T10) |
1.85(70.5) |
1.65(46.9) |
1.75 |
G.E + PFC125 + Std. NPK (T11) |
2.00(104.6) |
1.87(84.2) |
1.93 |
G.E + PFC125 + ½ NPK (T12) |
1.61(41.6) |
1.74(56.3) |
1.67 |
Mean |
1.62 |
1.61 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
0.08 |
0.03 |
0.12 |
CD (5%) |
0.23 |
0.09 |
0.32 |
Table 2 Average root volume of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
*Original values in Parenthesis
Interactions between treatment and soil condition (TxS) revealed that untreated plants raised in sterilised soil registered minimum and significantly low root volume (0.91 cc; Table 2) that was at par with controls (1.17 cc) and plants treated with G. etunicatum raised in unsterilised soil (T2: 1.13cc). Seedlings of unsterilised soil treated with T11 (2.0 cc) attained maximum and significantly high root volume which was at par with four treatments of unsterilised (T5: 1.73 cc; T7: 1.84 cc; T9: 1.88 cc; T10: 1.85 cc) and six treatments of sterilised soil (T3: 1.74 cc; T5: 1.72 cc; T7: 1.74 cc; T9: 1.68 cc; T11: 1.87 cc; T12: 1.74 cc). Plants treated with G. etunicatum and raised in sterilised soil (T2) had significantly more root volume (1.56 cc) than raised in unsterilised soil (1.13 cc).
Average root diameter
Irrespective of soil conditions, controls (T1) registered minimum and significantly low root diameter than treated plants (0.45mm; Table 3). Seedlings treated with combination of G. etunicatum, PFC125 and standard dose of NPK (T11: 1.03mm) registered maximum and significantly more diameter, which was at par with plants dually treated with G. etunicatum and standard dose of NPK (T7: 0.88mm), PFC125 and standard dose of NPK (T9: 0.95mm) and PFC125 and half dose of NPK (T10: 0.93mm). Irrespective of treatments, plants raised in sterilised soil (0.82mm) recorded significantly more average root diameter than seedlings of unsterilised soil (0.79mm).
Treatment |
Soil condition/Av. root dia. (cc) |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
0.50 |
0.41 |
0.45 |
Glomus etunicatum (G.E.; T2) |
0.49 |
0.75 |
0.62 |
Pseudomonas fluorescens (PFC125; T3) |
0.73 |
0.91 |
0.82 |
Std. NPK (T4) |
0.65 |
0.80 |
0.72 |
½ NPK (T5) |
0.86 |
0.86 |
0.86 |
G.E + PFC125 (T6) |
0.76 |
0.72 |
0.74 |
G.E + Std. NPK (T7) |
0.89 |
0.90 |
0.88 |
G.E + ½ NPK (T8) |
0.73 |
0.89 |
0.81 |
PFC125 + Std. NPK (T9) |
1.03 |
0.86 |
0.95 |
PFC125 + ½ NPK (T10) |
0.98 |
0.88 |
0.93 |
G.E + PFC125 + Std. NPK (T11) |
1.08 |
0.99 |
1.03 |
G.E + PFC125 + ½ NPK (T12) |
0.76 |
0.88 |
0.82 |
Mean |
0.79 |
0.82 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
0.06 |
0.02 |
0.08 |
CD (5%) |
0.16 |
0.06 |
0.22 |
Table 3 Average root diameter of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
Considering interactions between treatment and soil condition (TxS), untreated plants (T1: 0.41mm; Table 4) raised in sterilised soil recorded minimum and significantly low root diameter which was at with two treatments of unsterilised soil (T1: 0.50mm & T2: 0.49mm). The plants raised in unsterilised soil treated with combination of G. etunicatum, PFC125 and standard dose of NPK (T11: 1.08mm) registered maximum and significantly high root diameter which was at par with four treatments raised in unsterilised (T5: 0.86mm; T7: 0.89mm; T9: 1.03; T10: 0.98mm) and eight treatments of sterilised soil (T3: 0.91mm; T5: 0.86mm; T7: 0.90mm; T8: 0.89mm; T9: 0.86mm; T10: 0.88 mm; T11: 0.99 mm; T12: 0.88mm). Plants raised in sterilised soil and treated with G. etunicatum had significantly more root diameter (T2: 0.75mm) than their unsterilised counterparts (0.49 mm).
Treatment |
Soil condition/Av. root length (cm) |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
26.6 |
27.0 |
26.8 |
Glomus etunicatum (G.E.; T2) |
55.3 |
58.2 |
56.8 |
Pseudomonas fluorescens (PFC125; T3) |
55.3 |
59.9 |
57.6 |
Std. NPK (T4) |
66.5 |
59.0 |
62.8 |
½ NPK (T5) |
67.8 |
62.9 |
65.4 |
G.E + PFC125 (T6) |
67.0 |
49.9 |
58.5 |
G.E + Std. NPK (T7) |
67.4 |
57.9 |
62.7 |
G.E + ½ NPK (T8) |
54.8 |
53.1 |
54.0 |
PFC125 + Std. NPK (T9) |
63.8 |
58.1 |
61.0 |
PFC125 + ½ NPK (T10) |
60.7 |
52.6 |
56.6 |
G.E + PFC125 + Std. NPK (T11) |
74.3 |
65.5 |
69.9 |
G.E + PFC125 + ½ NPK (T12) |
54.8 |
61.4 |
58.1 |
Mean |
59.5 |
55.5 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
3.2 |
1.3 |
4.5 |
CD (5%) |
8.9 |
3.6 |
12.6 |
Table 4 Average root length of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
Average root length
The untreated plants measured minimum and significantly lower root length (26.8 cm; Table 4), irrespective of soil conditions. The combination of G. etunicatum, PFC125 and standard dose of NPK (T11) treated seedlings achieved significantly higher root length (69.9 cm) that was at par with plants treated with standard dose of NPK (T4: 62.8 cm), G. etunicatum and standard dose of NPK (T7: 62.7 cm) and PFC125 and standard dose of NPK (T9: 61.0 cm). Plants raised in unsterilised soil registed 59.5 cm root length which was significant than roots of sterilised soil (55.5 cm), irrespective of treatments.
Interaction between treatment and soil condition (TxS) reported that control plants raised in unsterilised (26.6 cm; Table 4) and sterilised (27.0 cm) soils registered minimum and significantly low root length. Among the treated plants, T11 (74.3 cm) treated seedlings raised in unsterilised soil registered maximum and significantly high root length which was at par with five treatments of unsterilised (T4: 66.5 cm; T5: 67.8 cm; T6: 67.0 cm; T7: 67.4 cm; T9: 63.8 cm) and two treatments of sterilised soil (T5: 62.9 cm; T11: 65.5 cm). Seedlings raised in unsterilised soil and dually treated with G. etunicatum and PFC125 (T6: 67.0 cm) recorded significantly more root length than plants raised in sterilised soil (49.9 cm).
Degree of root branching
The controls registered minimum and significantly lower root branching (0.80; Table 5), irrespective of soil conditions. The seedlings treated with G. etunicatum (T2: 1.52) recorded maximum and significantly more branching which was at par with plants treated dually with G. etunicatum and half dose of NPK (T8: 1.35). No significant effect of soil was observed in the experiment as plants raised in both types of soils had similar values, irrespective of treatments.
Treatment |
Soil condition/ Deg. of branch. |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
0.78 |
0.83 |
0.80 |
Glomus etunicatum (G.E.; T2) |
1.67 |
1.36 |
1.52 |
Pseudomonas fluorescens (PFC125; T3) |
1.48 |
1.17 |
1.32 |
Std. NPK (T4) |
1.35 |
1.32 |
1.34 |
½ NPK (T5) |
1.12 |
1.25 |
1.19 |
G.E + PFC125 (T6) |
1.27 |
1.30 |
1.29 |
G.E + Std. NPK (T7) |
1.15 |
1.26 |
1.21 |
G.E + ½ NPK (T8) |
1.42 |
1.27 |
1.35 |
PFC125 + Std. NPK (T9) |
1.15 |
1.31 |
1.23 |
PFC125 + ½ NPK (T10) |
1.35 |
1.21 |
1.28 |
G.E + PFC125 + Std. NPK (T11) |
1.20 |
1.11 |
1.15 |
G.E + PFC125 + ½ NPK (T12) |
1.29 |
1.22 |
1.26 |
Mean |
1.27 |
1.22 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
0.06 |
0.02 |
0.09 |
CD (5%) |
0.17 |
0.07 |
0.24 |
Table 5 Degree of root branching of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
Considering interactions between treatment and soil condition (TxS), controls raised in unsterilised (0.78; Table 6) and sterilised (0.83) soil registered minimum and significantly low root branching. Among the treated plants, seedlings raised in unsterilised soil treated with T2 (1.67) registered maximum and significantly highest root branching that was at par with plants treated with PFC125 (T3: 1.48) of same soil condition. Also T2 and T3 treated plants raised in unsterilised soil (1.67 & 1.48) had significantly more root branching than their counterparts in sterilised soil (1.36 & 1.17).
Treatment |
Soil condition/Dry root wt. (g) |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
0.62 |
0.56 |
0.59 |
Glomus etunicatum (G.E.; T2) |
0.97 |
0.92 |
0.95 |
Pseudomonas fluorescens (PFC125; T3) |
1.38 |
1.24 |
1.31 |
Std. NPK (T4) |
1.42 |
1.04 |
1.23 |
½ NPK (T5) |
1.52 |
1.31 |
1.42 |
G.E + PFC125 (T6) |
1.19 |
0.94 |
1.06 |
G.E + Std. NPK (T7) |
1.81 |
1.42 |
1.62 |
G.E + ½ NPK (T8) |
1.30 |
1.38 |
1.34 |
PFC125 + Std. NPK (T9) |
2.24 |
1.15 |
1.69 |
PFC125 + ½ NPK (T10) |
1.39 |
1.17 |
1.28 |
G.E + PFC125 + Std. NPK (T11) |
1.61 |
1.58 |
1.60 |
G.E + PFC125 + ½ NPK (T12) |
1.32 |
1.41 |
1.37 |
Mean |
1.40 |
1.18 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
0.10 |
0.04 |
0.14 |
CD (5%) |
0.28 |
0.11 |
0.37 |
Table 6 Dry root weight of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
Dry root weight
The controls recorded minimum and significantly lower root weight (T1: 0.59 g; Table 7), irrespective of soil conditions. The seedlings treated dually with PFC125 and standard dose of NPK (T9: 1.69 g) registered maximum and significantly higher weight which was at par with plants treated with half dose of NPK (T5: 1.42 g), G. etunicatum and standard dose of NPK (T7: 1.62 g), and G. etunicatum, PFC125 and standard dose of NPK (T11: 1.60 g). Irrespective of treatments, plants raised in unsterilised soil (1.40 g) recorded significantly more weight than sterilised soil (1.18 g).
Treatment |
Soil condition/Bac. count (cfu/ml) |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
5.04 |
3.31 |
4.17 |
Glomus etunicatum (G.E.; T2) |
4.02 |
2.13 |
3.07 |
Pseudomonas fluorescens (PFC125; T3) |
5.28 |
4.80 |
5.04 |
Std. NPK (T4) |
5.13 |
1.72 |
3.42 |
½ NPK (T5) |
4.52 |
4.06 |
4.29 |
G.E + PFC125 (T6) |
4.97 |
4.75 |
4.86 |
G.E + Std. NPK (T7) |
5.80 |
4.88 |
5.34 |
G.E + ½ NPK (T8) |
5.02 |
3.44 |
4.23 |
PFC125 + Std. NPK (T9) |
3.68 |
4.04 |
3.86 |
PFC125 + ½ NPK (T10) |
4.23 |
2.89 |
3.56 |
G.E + PFC125 + Std. NPK (T11) |
4.00 |
4.99 |
4.49 |
G.E + PFC125 + ½ NPK (T12) |
4.64 |
3.72 |
4.18 |
Mean |
4.69 |
3.73 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
0.39 |
0.16 |
0.55 |
CD (5%) |
1.11 |
0.45 |
1.57 |
Table 7 Fluorescent pseudomonads count of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
The interactions between treatment and soil condition (TxS) recorded that untreated plants of unsterilised (0.62 g; Table 5) and sterilised soils (0.56 g) had minimum and comparable dry root weight that was at par with seedlings raised in unsterilised (0.97 g) and sterilised (0.92 g) soil treated with G. etunicatum (T2). Among the treated plants, treatment T7 (1.81 g) raised in unsterilised soil registered highest and significantly higher weight which was at par with T5 (1.52 g) treated seedlings raised in unsterilised soil and with T11 treated plants raised in unsterilised (1.61 g) and sterilised (1.58 g) soils. Three treatments (T4: 1.42 vs. 1.04 g; T7: 1.81 vs. 1.42 g; T9: 2.24 vs. 1.15 g) raised in unsterilised soil gained significantly more root weight their counterparts in sterilised soil.
Root colonization by fluorescent pseudomonads
Plants treated with G. etunicatum (T2) supported minimum and significantly lower fluorescent pseudomonads (3.07 log cfu/ml; Table 6) which was at par with control seedlings (T1; 4.17 log cfu/ml), plants treated with standard dose of NPK (T4; 3.42 log cfu/ml), dually with PFC125 and standard dose of NPK (T9; 3.86 log cfu/ml), PFC125 and half dose of NPK (T10; 3.56 log cfu/ml) and combination of G. etunicatum, PFC125 and half dose of NPK (T12; 4.18 log cfu/ml), irrespective of soil conditions. The maximum bacterial counts were recorded in seedlings treated with G. etunicatum and standard dose of NPK (T7 : 5.34 log cfu/ml) which was at par with plants treated with PFC123 (T3: (5.04 log cfu/ml), half dose of NPK (T5: 4.29 log cfu/ml), G. etunicatum and PFC125 (T6: 4.86 log cfu/ml), G. etunicatum and half dose of NPK (T8: 4.23 log cfu/ml) and G. etunicatum, PFC125 and standard dose of NPK (T11: 4.49 log cfu/ml). Irrespective of treatments, plants raised in unsterilised soil supported more number of fluorescent pseudomonads (4.69 log cfu/ml) than seedlings raised in sterilised soil (3.73 log cfu/ml).
Considering interactions between treatment and soil condition (TxS), plants treated with T4 (1.72 log cfu/ml; Table 6) registered minimum and significantly low fluorescent pseudomonads which was at par with T2 (2.13 log cfu/ml) and T10 (2.89 log cfu/ml) treated seedlings raised in sterilised soil. Plants raised in unsterilised soil and treated with T7 (5.8 log cfu/ml) registered maximum and significantly higher bacterial count that was at par with eight treatments of unsterilised (T1: 5.04; T3: 5.28; T4: 5.13; T5: 4.52; T6: 4.97; T8: 5.02; T10: 4.23; T12: 4.64 log cfu/ml) and four treatments of sterilised soil (T3: 4.80; T6: 4.75; T7: 4.88; T11: 4.99). Plants of four treatments and raised in unsterilised soil (T1: 5.04 vs 3.31; T2: 4.02 vs. 2.13; T4: 5.13 vs. 1.72; T8: 5.02 vs. 3.44 log cfu/ml) registered significantly more fluorescent pseudomonas than seedlings raised in sterilised soil.
Root colonisation by G. etunicatum
Irrespective of soil condition, maximum root colonization was registered in seedlings treated dually with G. etunicatum and standard dose of NPK (T6: 72.4%; Table 8; Figure 5) which was at par with plants treated with G. etunicatum (T2: 72.2%). Minimum percent root colonization was registered in plants inoculated with PFC125 (T3: 19.9%) which was at par with control seedlings (T1: 25.9%) along with plants treated with standard dose of NPK (T4: 25.1%) and half dose of NPK (T5: 21.4%). Plants raised in unsterilised soil supported significantly more root colonization (49.8%) than sterilised raised seedlings (40.9%), irrespective of treatments.
Treatment |
Soil condition/root colonization (%) |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
37.8 |
13.9 |
25.9 |
Glomus etunicatum (G.E.; T2) |
62.7 |
81.7 |
72.2 |
Pseudomonas fluorescens (PFC125; T3) |
30.6 |
9.2 |
19.9 |
Std. NPK (T4) |
41.6 |
8.6 |
25.1 |
½ NPK (T5) |
30.9 |
11.9 |
21.4 |
G.E + PFC125 (T6) |
55.6 |
70.5 |
63.1 |
G.E + Std. NPK (T7) |
72.9 |
71.9 |
72.4 |
G.E + ½ NPK (T8) |
62.1 |
64.6 |
63.4 |
PFC125 + Std. NPK (T9) |
34.8 |
17.2 |
26.0 |
PFC125 + ½ NPK (T10) |
45.9 |
17.8 |
31.8 |
G.E + PFC125 + Std. NPK (T11) |
53.5 |
70.6 |
62.0 |
G.E + PFC125 + ½ NPK (T12) |
68.8 |
52.6 |
60.7 |
Mean |
49.8 |
40.9 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
2.1 |
0.9 |
3.0 |
CD (5%) |
6.1 |
2.5 |
8.6 |
Table 8 Root colonisation by G. etunicatum of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
Interactions between treatment and soil condition (TxS) revealed that plants raised in sterilised soil treated with standard dose of NPK (T4: 8.6%) registered minimum and significantly low root colonisation which was at par with seedlings raised in same soil condition treated with four treatments (T1: 13.0%; T3: 9.2%; T5: 11.9%; T9: 17.2%). Plants raised in sterilised soil treated with G. etunicatum (T2: 81.7%) recorded maximum and significantly high root colonisation followed by seedlings treated with T7 raised in unsterilised (72.9%) and sterilised soil (71.9%) which was at par with T6 (70.5%), T8 (64.6%) and T11 (70.6%) of sterilised soil and T12 (68.8%) treated plants raised in unsterilised soil. In majority of the cases where G. etunicatum is part of treatment, the plants raised in sterilised soil had more root colonisation than their counterparts.
Spore population
Irrespective of soil conditions, plants treated with standard dose of NPK (T4) and half dose of NPK (T5) recorded minimum spore population of mycorrhizae (1.02 each; Table 9; Figure 6) which was at par with controls (T1: 1.03), PFC125 (T3: 1.04), dually treated PFC125 and standard dose of NPK (T9: 1.05) as well as dually supplied with PFC125 and half dose of NPK (T10: 1.04). Seedlings treated with both G. etunicatum and standard dose of NPK supported maximum and significantly higher spore population (T7: 2.24). Irrespective of treatments, plants raised in unsterilised soil (1.54) had significantly more spores than sterilised ones (1.21).
Treatment |
Soil condition/Spore no. (/ml) |
Mean |
|
Unsterilised |
Sterilised |
||
Control (T1) |
1.51(32.7)* |
0.55(3.6) |
1.03 |
Glomus etunicatum (G.E.; T2) |
1.54(38.0) |
0.97(9.8) |
1.26 |
Pseudomonas fluorescens (PFC125; T3) |
1.51(33.2) |
0.56(3.7) |
1.04 |
Std. NPK (T4) |
1.47(30.1) |
0.57(3.8) |
1.02 |
½ NPK (T5) |
1.47(30.2) |
0.57(3.8) |
1.02 |
G.E + PFC125 (T6) |
1.64(44.2) |
1.42(27.2) |
1.53 |
G.E + Std. NPK (T7) |
2.16(153.0) |
2.32(219.7) |
2.24 |
G.E + ½ NPK (T8) |
1.60(40.6) |
2.09(132.0) |
1.85 |
PFC125 + Std. NPK (T9) |
1.49(30.6) |
0.61(4.1) |
1.05 |
PFC125 + ½ NPK (T10) |
1.50(31.7) |
0.59(3.9) |
1.04 |
G.E + PFC125 + Std. NPK (T11) |
1.77(61.4) |
2.09(144.4) |
1.93 |
G.E + PFC125 + ½ NPK (T12) |
1.47(30.1) |
2.18(153.6) |
1.82 |
Mean |
1.59 |
1.21 |
|
|
Treatment (T) |
Soil condition (S) |
Interaction (TxS) |
SEM |
0.06 |
0.02 |
0.08 |
CD (5%) |
0.16 |
0.07 |
0.23 |
Table 9 Spore population of G. etunicatum of D. strictus seedlings raised in unsterilised and sterilised soils after 105 days of transplanting
*Original values are in parentheses.
Interactions between treatment and soil condition (TxS) revealed that untreated seedlings raised in sterilised soil registered minimum and significantly low spore population (0.55; Table 9) which was at par with plants of five treatments of same soil condition (T3: 0.56; T4: 0.57; T5: 0.57; T9: 0.61; T10: 0.59). Among the treated plants, T7 seedlings raised in unsterilised (2.16) and sterilised (2.32) soils registered maximum and significantly high spore population which was at par with three treatments of sterilised soil (T8: 2.09; T11: 2.09; T12: 2.18). Plants treated with T6 (1.64 vs. 1.42) and T7 (2.16 vs. 2.32) registered no significant change in spore population between unsterilised and sterilised soils.
The effect of microbial inoculants on the root architecture of bamboo seedlings was also investigated. The study revealed that the combination of G. etunicatum, PFC125 and standard dose of NPK (T11) increased the root volume, average root diameter and average root length. The degree of root branching was increased by the application of G. etunicatum (T2). These results are in agreement with the observation reported by Gamalero et al.14 They too found that co–inoculation of P. fluorescens and G. mosseae strongly affected the root architecture of tomato plants and helped in improving plant mineral nutrition by increasing leaf P content. Influence of P. fluorescens on root volume and length in D. strictus seedlings is in coherence with the above findings. Berta et al.15 stated that longer root systems are more adapted and concentrated to soil exploration and exploitation.15 Enhancement of total root volume and length of shallow root system of bamboo by the bacterium and fungus can be of extra advantage of this grass where reaching out for nutrients and water becomes more easy due to boost to root growth. Berta et al.16 and Gamalero et al.15 reported that mycorrhizae (G. mosseae) can affect root architecture, especially the degree of root branching.15 They stated that increase in root branching improves the ability of plants to absorb and transport nutrients. The synergistic effect of microbial inoculants (G. etunicatum and P. fluorescens (T11)) on root volume, length and branching in bamboo seedlings might be promoting efficient exploration of surrounding soil, nutrient transport and uptake that could express in increased tillering, plant height, collar diameter, dry shoot weight and total shoot P content.
I acknowledge the Forest Research Institute for their support in providing facilities for the research.
Authors declare that there is no conflict of interest.
©2018 Das, et al. This is an open access article distributed under the terms of the, which permits unrestricted use, distribution, and build upon your work non-commercially.
