A gigantic desmoplastic fibroma resembling a malignant neoplasm: an intriguing case report

doi:10.15406/ijrrt.2017.04.00100

International Journal of

eISSN: 2574-8084

Radiology & Radiation Therapy

Case Report Volume 4 Issue 3

A gigantic desmoplastic fibroma resembling a malignant neoplasm: an intriguing case report

Prashant Ramachandra,

Verify Captcha

Regret for the inconvenience: we are taking measures to prevent fraudulent form submissions by extractors and page crawlers. Please type the correct Captcha word to see email ID.

Vandrangi Sameer Kumar, Narendra Kumar Yandrapu, Sravya Reddy

Department of oral and maxillofacial pathology, India

Correspondence: Prashant Ramachandra, Department of oral and maxillofacial pathology, Krishnadevaraya college of dental sciences, Bangalore, India

Received: May 29, 2017 | Published: October 27, 2017

Citation: Ramachandra P, Kumar VS, Yandrapu NK, et al. A gigantic desmoplastic fibroma resembling a malignant neoplasm: an intriguing case report. Int J Radiol Radiat Ther. 2017;4(3):389-391. DOI: 10.15406/ijrrt.2017.04.00100

Download PDF

Abstract

Desmoplastic fibromas of bone have been described as a rare, non-metastasizing, locally aggressive, benign lesions that histologically resemble a desmoid tumour of the soft tissue. Since his original description, a number of case reports have been published, as many as 150. They are very common in mandible but here we report a fascinating case in a 21year old young boy in the body of mandible which has grown to gigantic proportion in a short period of time and showed very aggressive radiographic presentation unlike conventional cases. In the present case, we have described clinical, radiological and histopathological features of Desmoplastic fibroma in detail. The gigantic size and aggressiveness of the lesion are the highlights in this case report.

Keywords: spindle cell neoplasm, desmoplastic fibroma, fibrosarcoma, hot spot mutations

Abbreviations

OPG, orthopantomogram; CT, computed tomography; DF, desmoplastic fibroma; WHO, world health organization

Introduction

Desmoplastic fibromas of bone has been described as a rare, non-metastasizing, locally aggressive, benign lesions that histologically resembles a desmoid tumour of the soft tissue.^1,2 It was initially described by Jaffe in 1958 who highlighted the histological resemblance to aggressive fibromatosis (desmoid tumour).³ Since his original description, approximately 150 case reports have been published.¹ Desmoplastic fibromas are very common in mandible as they constitute approximately 86% of total cases cases⁴ but the current case report illustrates an interesting neoplasm which has grown to gigantic proportion in a short period of time and showed very aggressive radiographic presentation unlike conventional cases.

Case report

A 21year old male patient presented with a history of swelling in left jaw region since 6months which actually manifested after extraction of two of his posterior teeth. The swelling is asymptomatic but patient is worried because of abnormal growth in and around the extraction site. On extraoral examination there was a firm swelling present on the left side of the jaw which is diffuse, fixed to the body of mandible. Skin over the swelling was normal (Figure 1).

Figure 1 Frontal photograph showing diffuse swelling over left lower jaw.

Intra-orally a huge swelling is present in the labial vestibule extending from mesial aspect of 33 to 38 and also extending towards the floor of the mouth. It is appearing fleshy with overlying mucosa exhibiting pale and erythematous areas and vestibular obliteration is evident. It is solitary, multi lobulated, well circumscribed swelling, irregular in shape, measuring about 6 x 5 x 4cm in size (Figure 2). On palpation swelling was very firm, nontender, and rough. Bone seems evidently involved on palpating lower border. Considering the huge size of the mass and rapid growth the clinical differentials we considered were odontogenic tumors such as Ameloblastic fibroma, Odontogenic Myxoma, Ameloblastoma; Primary intraosseous Oral Squamous cell carcinoma, Intraosseous Muco-epidermoid Carcinoma, and other Sarcomas such as Osteosarcoma, Ewing’s Sarcoma or Fibrosarcoma.

Figure 2 Intra oral photograph showing multi-lobular overgrowth in buccal vestibule extending towards floor of mouth.

Orthopantomogram (OPG) showed a well defined radiolucent lesion extending from 35 to 38 involving lower border of mandible. The lesion has displaced the roots of 35 and 38. There is no evident root resorption. Scalloped areas were prominent in the lower border of mandible. There were no calcified foci in the radiolucent area. There is trace of mandibular canal posterior to 38 but it appears to be involved or pushed in the lesional area (Figure 3).

Figure 3 Orthopantamograph showing well defined radiolucent lesion involving lower border of mandible and prominent scalloped areas.

Coronal CT scan of the lesion showed irregular radiodense areas in left mandible which were extending into soft tissues and floor of mouth (Figure 4). 3-D CT Scan shows multiple perforations of irregular sizes and shapes (Figure 5). Axial- CT shows expanded bony cortices in the form of locules which are characteristic of benign lesion (Figure 6) but overall findings indicate a frank malignant lesion. Thus we have considered intraosseous Squamous cell carcinoma, Odontogenic Carcinomas and sarcomas, Intraosseous Mucoepidermoid carcinoma, Other Sarcomas such as Ewings Sarcoma, Osteosarcoma as radiological differentials. Left segmental mandibulectomy was done under general anaesthesia (Figure 7).

Figure 4 Coronal CT scan showing Radiodense areas extending into soft tissues and floor of mouth.

Figure 5 3-Dimensional CT Scan depicting multiple perforations on buccal and inferior surface of body of mandible.

Figure 6 Axial- CT shows expanded bony cortices in the form of locules.

Figure 7 segmental mandibulectomy specimen measuring 9X 6X 5 cm.

Microscopic examination revealed presence of well encapsulated lesional tissue mass composed of fascicles of uniform cells (Figure 8). On closer examination, the neoplasm is composed of spindle cells in short fascicles and whorls (Figure 9). The fusiform cells depict indistinct cell borders, scanty cytoplasm and slender tapering nuclei without any atypia (Figure 10). Few normal mitoses are present. Pockets of chronic lympho-plasmacytic infiltrate and scattered mast cells are seen (Figure 11).

Figure 8 Low power histopathologic image shows an encapsulated lesion.

Figure 9 Low power image shows spindle cells in short fascicles and whorls.

Figure 10 High power image shows fusiform cells depicting indistinct cell borders, scanty cytoplasm and slender tapering nuclei without atypia.

Figure 11 High power image shows pockets of chronic lympho-plasmacytic infiltrate and few scattered mast cells.

As of now it is quite clear that

It is primarily bone pathology (Intra-osseous Origin): because a pathologic process beginning within bone and secondarily extending into soft tissues typically follows inside–out principle, where the soft tissue mass is smaller than the degree of bone destruction.

It’s a Spindle cell neoplasm: Histopathologic differentials which we have considered based on histological findings are Cellular benign fibrous histocytoma, fibromatosis, nodular fascitis, low grade fibrosarcoma, inflammatory myofibroblastic tumor. Immunohistochemistry was performed and the neoplastic cells are negative for desmin, S-100, CD-34, EMA and Ki-67 is very low i.e less than 1/10 HPF. So based on the morphological features and exclusion of sarcomas based on immunohistochemistry findings, the final diagnosis of Desmoplastic fibroma was given.

Discussion

The desmoplastic fibroma (DF) is a rare, fibroblastic lesion of bone that resembles histological counterpart of desmoid tumor of soft tissue. Although classified as benign, it frequently demonstrates aggressive behavior, often causing tooth mobility, extensive bone destruction, as seen in the current case report and has a moderate to high recurrence rate.^6,7Activating CTNNB1 hotspot mutations or APC mutations are driving events^8,9 for these locally aggressive tumors.

According to World Health Organization (WHO) Desmoplastic fibroma is defined as a locally aggressive (myo) fibroblastic lesion of bone. It is also known as the desmoid tumor of bone. It is seen in patients aged less than 30years. Desmoplastic fibromas are very common in mandible as they constitute approximately 86% cases in mandible⁴ with a predilection for the ramus and angle region, Usually the lesions are slow growing⁶ and radiographically well defined but the presence of such a massive lesion which has grown in such a short time span with multiple buccal and lingual cortical plate perforations and infiltration of floor of mouth and soft tissues is a very rare finding¹⁰ when we compare current case report with past cases.

The fact that this did not happen to be a malignancy was such a relief for the patient. So not every aggressive appearing neoplasm should be a matter of worry for the clinician or patient. Current case report reiterates that histologic examination is the gold standard for diagnosis and immunohistochemistry adds so much value to the diagnosis not only when it is positive but also when there is no staining. The patient is under follow up and there was no recurrence as of now.

Conclusion

It is important to include desmoplastic fibroma in the list of differential diagnoses of extremely aggressive neoplasms in the jaw because failure to do so can lead to significant patient morbidities.
