Effects of transport using an unmanned aerial vehicle on blood samples for cross-matching tests

doi:10.15406/htij.2020.08.00232

eISSN: 2469-2778

Hematology & Transfusion International Journal

Letter to Editor Volume 8 Issue 5

Effects of transport using an unmanned aerial vehicle on blood samples for cross-matching tests

Michiyo Nakahara,¹ Miyuki Teratani,¹ Koki Yakushiji,² Fumiatsu Yakushiji,³ Hiroshi Fujita⁴

Verify Captcha

Regret for the inconvenience: we are taking measures to prevent fraudulent form submissions by extractors and page crawlers. Please type the correct Captcha word to see email ID.

¹Clinical Laboratory, Tokyo Metropolitan Bokutoh Hospital, Japan
²Graduate School of Media and Governance, Keio University, Japan
³Department of Internal Medicine, Tokyo Metropolitan Bokutoh Hospital, Japan
⁴Department of Transfusion Medicine, Tokyo Metropolitan Bokutoh Hospital, Japan

Correspondence: Hiroshi Fujita, MD, PhD, Director of Department of Transfusion Medicine, Tokyo Metropolitan Bokutoh Hospital, 4-23-15, Koutoubashi, Sumida-ku, Tokyo

Received: August 21, 2020 | Published: September 17, 2020

Citation: Nakahara M, Teratani M, Yakushiji K, et al. Effects of transport using an unmanned aerial vehicle on blood samples for cross-matching tests. Hematol Transfus Int J. 2020;8(5):93-95. DOI: 10.15406/htij.2020.08.00232

Download PDF

Abstract

Objective: This study aimed to examine the effects of transport using an unmanned aerial vehicle (UAV) on blood samples for cross-matching tests in the transfusion of red blood cell solution.

Materials and methods: Two bags of red blood cell (RBC) solution (blood type, A, RBC#1 and #2; 280 mL per bag) were obtained from the Japan Red Cross Society. The RBC solution in each bag was further separated into three bags (93 mL per bag). The UAV group consisted of RBC solution with a segment tube containing the whole blood in a temperature controlled cooler box transported using an UAV. The control group consisted of RBC solution with a segment tube containing the whole blood in an in-house refrigerator that was not transported. Samples from the RBC solution were collected on day 10 (2 days before transport) and day 13 (day after transport), and lactate dehydrogenase (LD), potassium, blood sugar, and lactic acid levels were measured. After transport, cross-matching tests were performed using whole blood in the segment tubes and patient`s blood (blood type, type A).

Results: We compared the biochemistry between the UAV and control group and found no significant differences, except for LD level. Although the LD level in the UAV group slightly increased compared with that in the control group, the whole blood containing the segment tubes was not hemolyzed, and cross-matching tests were performed.

Conclusion: We could fly and transport an RBC solution with segment tubes using an UAV, and this mode of transport did not affect the cross-matching tests, despite mild hemolysis in the RBC solutions.

Keywords: disaster, active transport refrigerator, red blood cell solution

Abbreviations

RBC solution, red blood cell solution; UAV, unmanned aerial vehicle.

Letter to the editor

We first reported the transport of red blood cell (RBC) solutions using an unmanned aerial vehicle (UAV) in Japan.¹ In addition, we repeated the transport of the RBC solution using an UAV in various conditions.² In these studies, we found mild hemolysis in the transported RBC solution.^1,2 We previously reported the long-distance transport of an RBC solution from Tokyo to Ogasawara Islands using an active transport refrigerator (ATR) (FUJIFILM Toyama Chemical Co. Ltd., Tokyo, Japan) by ship.³ We could safely move the RBC solutions without hemolysis.³ We also reported that transport of RBC solution by car induced hemolysis under inappropriately temperature-controlled and oscillated conditions.⁴ However, the effects of the transport using an UAV on the whole blood containing the segment tubes were neither examined nor reported.

In this letter, we show the data from the experiment performed in the Nagano Tomi Fields, where our driving UAV was examined.⁵ Two bags of RBC solution (blood type A, day 10) were transported in an ATR from Tokyo to Nagano by car. Using an UAV (M1000, Mazex Co. Ltd., Osaka) for 300 m at a maximum height of 15 m and an average speed of 15 km/h, the four bags of RBC solution with segment tubes in the temperature-controlled cooler box (Campers Collection, Yamazen, Corp., Tokyo, Japan) were transported. An electronic watch logger recorded the temperature each minute (KT-255U, Fujita Electric Works, Ltd, Kanagawa, Japan), and a solid coolant that changed to a liquid state at approximately 2~6°C was used to control the temperature of the blood packs (Cold-packs Type 3, JSP Corp., Tokyo, Japan). We compared the biochemistry between the UAV and control groups and found no significant differences, except for the LD level (data not shown). Although the LD level in the UAV group slightly increased, the LD level post-filtration was extremely similar between the UAV and control groups (Table 1). In contrast, the whole blood containing the segment tubes grossly did not hemolyzed (Figure 1A & B). As shown in Figure 1C, the supernatant of RBC solution transported by a drone revealed mild hemolysis. We first cross-matched for compatible blood from the patients with blood type A (Figure 2A, saline method; 2B, indirect antiglobulin test).

	% of control (LD)	% of control (LD)
	Post-transportation	Post-filtration
RBC #1 RBC #1-1 drone RBC#1-2 drone RBC#1-3 in-house	102±3* 106±1* 92±2	114±3 135±3 133±6
RBC #2 RBC #2-1 drone RBC#2-2 drone RBC#2-3 in-house	166±1 194±1* 169±2	112±1 117±1 112±1

Table 1 Comparison of lactic dehydrogenase level of the red blood cell solution between the unmanned aerial vehicle (UAV) and control groups
* Post-filtration implies that the RBC solution was passed through a transfusion filter (Terumo Co. Tokyo) and used at the transfusion practice.
We calculated % of control (LD) as follows:
|(LD level post-stored or post-filtered) ÷　mean value of LD level pre-stored or pre-filtered × 100 (%)
Data are expressed as group mean ± standard deviation of the mean.

Figure 1 Whole blood in the segment tubes did not show hemolysis, and the red blood cell solution showed mild hemolysis.
The UAV (M1000, Mazex Co. Ltd., Osaka) safely transported the RBC solution with segment tubes in the Nagano Tomi Fields, where our driving UAV was examined.
(A) Gross findings of segment tubes in the RBC#1 transported by drone (right) and in-house storage (left)
(B) Gross findings of segment tubes in the RBC#2 transported by drone (right) and in-house storage (left)
(C) Supernatant of RBC #1
LD level (IU/L) was measured by BML Laboratories (Tokyo, Japan).

Figure 2 Results on the cross-matching tests.
We cross-matched for compatible blood from the patients with the samples in the segment tubes.
(A) Saline method
(B) Indirect antiglobulin test
Cross-matching test is a routine laboratory test for transfusion. 1 denotes a major test, and 2 denotes a minor test. AC, auto-control; PC, positive control

Conclusion

In conclusion, we could fly and transport an RBC solution with segment tubes using an UAV, and this mode of transport did not significantly affect the cross-matching tests, despite mild hemolysis in the RBC solutions (Table 1, Figure 1C). Therefore, we envisage the possibility that RBC solutions can be transported using an UAV in the event of a disaster, with the viewpoints of cross-matching tests for transfusion.
