16S rRNA sequence-based analysis of bacterial communities associated with the selected mosses of Mount Abu (Rajasthan), India

Afroz Alam, Shivangi Pandey, Saumya Pandey

Department of Bioscience and Biotechnology, Banasthali Vidyapith University, India

Correspondence: Afroz Alam, Department of Bioscience and Biotechnology, Banasthali Vidyapith University, Tonk,304022, Rajasthan, India

Received: August 13, 2019 | Published: October 18, 2019

Citation: Saumya P, Shivangi P, Alam A. 16S rRNA sequence-based analysis of bacterial communities associated with the selected mosses of Mount Abu (Rajasthan), India. Biodiversity Int J. 2019;3(5):230-233. DOI: 10.15406/bij.2019.03.00149

Download PDF


The phyllosphere of bryophytes offers an excellent habitat to various other microorganism to flourish. This fascinating association among bryophytes and soil borne microorganisms have significant ecological and physiological roles including N2 fixation, soil-enrichment, promotion of protonemal growth and bud formation. However, our understanding regarding the ecological aspects of this association is still little known, and if consider at molecular level it becomes rare. So far, only sporadic works have been done, and for better understanding related to this ignored concern and there is a necessity to address this. Hence, the present study was done to elucidate the structure and biological roles of bacterial diversity coupled with the bryophytes and their dynamics on selected taxa in different ecosystems. Phylogenetic analysis of bacterial community associated with selected mosses was carried out. The work is primarily based on the 16S rRNA sequencing approach. Moss taxa viz., Anoectangium clarum Mitt., Hyophila involuta (Hook.) A. Jaeger and Atrichhum undulatum (Hedw.) P. Beauv., were collected from different locations of Mount Abu, Rajasthan. The outcome of the study estimated that the microbial communities associated with these mosses belong mainly to phylum proteobacteria and fermicutes with the dominance of γ-proteobacteria. This genus found frequently associated to the species of different habitat, soil, near water channel and the rocks are Pseudomonas, Aeromonas, Routella and Halobascillus. This study provides the groundwork information about the exceptional relationship of these bacteria with mosses and would be helpful for the future research in this direction.

Keywords: bacterial community, bryophytes, endophytes, mosses


FISH, fluorescent in situ hybridization; CLSM, confocal laser scanning microscopy; SSCP, single-strand conformation polymorphism


The plant-microbes association is considered indispensable for the growth and development of plants.1 Bacteria associated with the plants are mainly endophytes and barely epiphytes that help to improve the plant growth by promoting soil enrichment,2 degradation of organic pollutants,3–5 plant hormones and vitamin synthesis, N2 fixation, suppression of the development of bacterial and fungal diseases,6–7 and can also enhance the host capability to adapt under extreme environment.8 Bacterial associations are present in nearly all the plant species that exists on earth.9 Despite this prevalent dependence, astoundingly, the majority of research focused only on the higher plants-bacterial association and the structure or diversity of bacteria associated with lower plants such as bryophytes has been neglected.10 Bryophytes are the primitive and simplest non-vascular plants/first land plants that are composed of mosses, liverworts and hornworts, and are considered to be the ancestors of pteridophytes and all other tracheophytes.11–12 Bryophytes consists of nearly 25,000 species worldwide13 distributed in diverse ecological condition ranging from polar and alpine regions to tropic14 and also played an important role in biota formation along with the settlement of land by plants.15 Bryophytes have been suggested as excellent candidates for evaluating the ecological and evolutionary impacts of the habitat fragmentation due to their global ubiquity, fast-growing nature, substrate specificity, and dominant haploid gametophytes.14 They have also been adopted and employed as model organisms and exploited for different kinds of biotechnological applications.16–17 Bryophytes play imperative roles in nutrient cycling and can act as bio-indicators of air pollutants or heavy metals, making them crucial to the environmental health of many ecosystems.18

Nowadays, bryophytes are gaining great attention from several researchers because of its distinctive properties and availability of biotechnological tools to exploit it in different aspects useful for better understanding of evolution and ecology. A number of studies showed that bryophytes-microorganism association is prevalent in the environment,10,19–21 but till now the nature and bio-functional diversity of these microbial communities inhabiting in/on the bryophytes remains unknown.20 This draws the attention of several researchers to study the bryophytes-associated microorganisms and their relationship with bryophytes and its habitat. Currently the detailed understanding of microbial community structure and its associated biological role are available for only few genera of bryophytes.10,22 The peat moss, Sphagnum is the most exploited genus among bryophytes to study the abundance, structure and function of the endo/ectophytic bacteria associated with plant.7,19,24 Apart from this, other genera such as Hygroamblystegium spp., Entodon spp., Grimmiia spp.,21 Brachythecium spp., Haplocladium spp., Bryum spp.,20 Funaria spp.,10 Tortula19 has been studied for microbial association. Several studies provide insights into the correlation between the ecosystem or geographical region and abundance of microbial community.20,21 Several methods has been used to study the bryophytes-microbial association such as scanning electron/fluorescence microscopy,10 Fluorescent in situ Hybridization (FISH) and Confocal Laser Scanning Microscopy (CLSM),7 Single-strand conformation polymorphism (SSCP),19 16S rRNA and 16S rDNA sequencing,21 DGGE-PCR sequencing25 and Illumina sequencing.26

Microbial strains such Burkholderia, Serratia, Hafnia, Pantoea, Methanobacteria and Methylobacteria were found abundantly as endophytes, epiphytes or both, in some mosses.19,22 Some of these microorganisms possess unique characteristic property such as N2 fixation, mineral phosphate solublization, ACC deaminase activity and PGR (Plant Growth Regulators) production, which make them valuable tools for agricultural biotechnology.27 In addition, many of isolated moss-associated bacteria have antagonistic property against several phytopathogenic fungi.28 In this study, the diversity and community structure of three bryophyte species collected from three different locations of Mount Abu were investigated and compared based on culture-independent approach of 16S rRNA sequencing method of Tian.21 As the study is based on only a few sequences so it provides only the groundwork scenario of microbial community diversity and the relationship between the ecosystem and bryophyte species in association with bacterial community. For comprehensive and significant evaluation of the associated microbial community of the Mount Abu region, diverse ecosystem and associated mosses should be taken into account for upcoming study.

Materials and methods

Sampling sites and surface treatment

To evaluate the bacterial community structure of the bryophytes three mosses, Anoectangium clarum, Hyophila involuta and Atrichum undulatum were collected during the spring season of 2014 from Mount Abu, which is located in the western part of India with longitude and latitude 72.7083°E 24.5925°N respectively. Three sites were selected for sampling; (a) surface of rock, (b) moist soil, (c) near water channels (Table 1). The collected samples were submitted and identified as taxonomically distinct species at Banasthali University Herbarium, Rajasthan and used for further analysis. The samples were washed with running tap water to remove attached soil. Then, the samples were immersed in 70% ethanol for 3 min and followed by washing five times with sterile distilled water.


Name of Samples

Herbarium number

Source of Samples


Anoectangium clarum Mitt. (Pottiaceae)


Moist Soil


Hyophila involuta (Hook.) Jaeg. (Pottiaceae)


Near water Channel


Atrichum undulatum (Hedw.) P. Beauv. (Polytrichaceae)


Shaded rocky ledges

Table 1 The three mosses collected from different locations of Mount Abu, Rajasthan

Total DNA extraction and PCR amplification

The genomic DNA of bacterial cell consortia was extracted from 1gm of surface treated moss using Fast DNA spin kit for soil (MPBIO) according to manufacturer’s instruction. The eluted DNA was used diluted and used for the PCR reaction.

Amplification of bacterial 16S rRNA genes and Phylogenetic analysis

The 16S rRNA gene fragments were amplified with the universal bacterial primer sets 799F (50-AACAGGATTAGATACCCTTG-30)29 and 1492R (50-TACGGYTACCTTGTTACGACT-30).30 The PCR was performed using a 15ul mixture containing 25 ng/µl of DNA 2.5 mM each of dNTPs, 1.5 mM MgCl2, 10µM of forward and reverse primers and, 0.2 U of Taq DNA polymerase (Genei). The amplifications were performed using a thermal cycler (Primus 96) with subsequent plan, i.e. initial denaturation at 94oC for 5min; 35 cycles of 1 min at 94oC, 1 min at annealing temperature 53oC and 2 min at 72oC; and a final elongation step of 5 min at 72oC. PCR products were separated by the electrophoresis technique using a 1% agarose gel. The six bands of approximately 250 bp in size were excised and purified by the Hiyield Gel/PCR DNA Mini Kit as described by the manufacturer (Figure 1). The sequencing of the purified eluted product was performed by Applied Biosystems (India). Similarity searches in GenBank were performed using BLAST.31 The DNA sequences were analyzed for the closest neighbours among sequenced 16 rDNA regions of different bands using PAUP version 4 (Figure 2).32

Figure 1 16S rRNA PCR gel of bryophytes associated bacteria of three different locations of Mount Abu, Rajasthan. Sample loaded on 1.5% agarose gel lanes are: L, Medium range DNA ladder and lane M, N and S indicate samples isolated from moist soil, near water channel and rocks, respectively.

Figure 2 Neighbor-joining Phylogenetic analysis constructed based on comparative analysis of 6 individual amplified 16S rRNA gene of the bacterial community structure associated with three bryophyte species using multiple alignments CLUSTALW.

Result and discussion

16S rRNA sequencing approach is most widely used method to study biological community structure associated with bryophytes species.21 In the present study, five out of six excised and sequenced bands from agarose gel from three bryophyte species were assigned taxonomic phyla (Figure 1). The phylogenetic analysis showed the presence of two phyla, proteobacteria and fermicutes with predomination of γ-Proteobacteria. The result showed that the bacterial communities inhabiting bryophytes species collected from soil and near water channel consists mainly of proteobacteria while those from rocks has both proteobacteria and fermicutes (Table 2). This study is in agreement with earlier reports that the shift in ecosystem shift brings the change in predominance of bacterial communities inhabiting the associated hosts.20,33

Closest BLAST matches


Location of Samples

Bryophyte species

Closest matches characterization





Acession No.

% identity

Taxonomic group

Pseudomonas taiwanensis strain SJPS KUD54


Moist soil

Anoectangium clarum



γ -proteobacteria

Aeromonas veronii strain Philippines-An11


Moist soil

Anoectangium clarum



γ -proteobacteria

Pseudomonas fluorescens strain D19


Near water channel

Hyophila involuta



γ -proteobacteria

Uncultured α-proteobacterium clone RLBp5566


Near water channel

Hyophila involuta




Routella terrigena strain 35CL


Shaded rocky ledges

Atrichum undulatum



γ -proteobacteria

Halobascillus sp. HPB32


Shaded rocky ledges

Atrichum undulatum




Table 2 Phylogenetic analysis of the bacterial community structure of three bryophyte species isolated from three different locations of Mount Abu, Rajasthan

Bacterial species identified in all geographical regions belong to three phylogenetical group α-proteobacteria, γ-proteobacteria and fermicutes. The γ-proteobacteria genera such as Pseudomonas and Aeromonas were found associated with bryophyte species of soil habitat (Anoectangium clarum). And also the bryophytes species (Hyophila involuta) collected from water channel were found associated with γ-proteobacteria i.e. Pseudomonas and uncultutured α-proteobacteria. In contrast, bryophyte species (Atrichum undulatum) collected from rock habitat contains both γ-proteobacteria and fermicutes genera, Pseudomonas and Halobacillus respectively. The genus Pseudomonas was found associated with bryophyte species of both soil and rock habitat. This result showed that the bacteria community structures are different at only species level irrespective of the habitat of bryophyte species. Bragina et al.,22 reported that the bacterial community structures are highly specific to their masses. However, the study involves only a few sequences due to lack of resources and contamination so the evaluation of dependency of bacterial community structure on the specific ecosystem required further investigation. This study is only preliminary approach to understand the microbial community structure and its relation with bryophytes grown in different habitat of Mount Abu.

The bacteria assigned of this report are well known as plant-associated bacteria for their impact on plant capability in diverse ways. The bacterial association may promote plant growth and health via production of phytohormones (Aeromonas & Halobascillus) and N2 fixation (Pseudomonas & Routella) and antagonistic property. Earlier, Opelt et al.,23 reported that genus Pseudomonas has very efficient antagonistic property.34,35 According to the study, the productions of active substances by moss-associated bacteria are approximately two folds are higher than plant-associated bacteria.19 The microbial communities residing in mosses are not only beneficial for growth and health of plants but also for biotechnological applications. Thus, the knowledge of bacterial community structure and its relationship with habitat and bryophyte species as well as the benefits of associated bacteria to plant are essential to evolve strategies for their exploitation.


We report the bacterial community structure of three mosses collected from three different habitats of Mount Abu. The data indicate the presence of two phyla proteobacteria and fermicutes associated with mosses. However, due to inadequate resources and contamination in samples the only the few microbial species and their distribution in different habitat were studied. So this study is preliminary attempt to understand the microbial community structure of mosses from different habitat of Mount Abu. Further study can be done to study other associated microbial community and its biological role and also its specificity is host specific or habitat specific and the reason for fluctuation of diversity in different habitats.


The authors are grateful to Professor Aditya Shastri, Vice Chancellor, Banasthali Vidyapith, Rajasthan for his encouragement and support.

Conflict of interest

The author declares there is no conflict of interest.
