Dextrocardia (DC) is a rare congenital anomaly with a prevalence of 1 in 10,000 births. The incidence of coronary artery disease in such patients is thought to be similar to that of the general population. Percutaneous coronary intervention (PCI) in dextrocardia presents several challenges due to abnormal location of the heart, mirror image pattern of aortic arch and its branches, and abnormal coronary origin and orientation. There have been few case reports of PCI in patients with dextrocardia and they mostly have been done via transfemoral access. We present first case of successful transradial PCI using a 5Fr system in a patient with DC. Literature review of technical considerations, including our own recommendations for guide catheter selection is discussed. We also review the anatomic variations and epidemiology of DC. Although access-complications for transradial PCI is known to be lower than that of the transfemoral approach but challenges in technique have limited the popularity of the former. Our report demonstrates the safety and feasibility of transradial angiography and PCI in the rare patient with DC.

Keywords: acute coronary syndrome, dextrocardia, transradial intervention, percutaneous coronary intervention

DC, dextrocardia; PCI, percutaneous coronary intervention; CAD, coronary artery disease; ECG, electrocardiogram; LAD, left anterior descending artery; Fr, french; LAO, left anterior oblique; RAO, right-anterior-oblique; RCA, right coronary artery; JR4, judkins right 4 cm; JL4, judkins left 4-cm; LCX, left circumflex; BMW, balanced middle weight

Situs inversus with dextrocardia is a rare congenital anomaly of development characterized by a mirror image position of the heart and abdominal viscera.^1,2 Although it is rare clinical phenomenon, the association with coronary artery disease (CAD) is the same frequency as in the general population.³ Few cases of situs inversus and dextrocardia complicated with CAD were reported before. The coronary angiography and percutaneous coronary intervention (PCI) in these patients is technically difficult and requires some modifications, such as mirror-image angiographic views, proper catheter selection and catheter manipulation for selective cannulation of the coronaries. Here we report a case of a male patient with dextrocardia and CAD was successfully treated with transradial PCI.

A 55-year old man was transferred from one of our referring hospitals with early post infarct unstable angina, having chest pain in the right side of the chest radiating to the right shoulder and the back, following an anterior ST-elevation myocardial infarction for which he had received thrombolytic therapy. He was a known case of dextrocardia with Kartagener syndrome, diabetic and smoker. Physical examination was unremarkable except for findings consistent with dextrocardia. Apart from raised troponine-I and blood sugar, his routine laboratory tests were within normal values. 12-lead Electrocardiogram (ECG) showed a negative P wave lead-I and aVL and positive P and R waves in aVR together with Q waves in inferior leads. Reversed chest leads showed QS in V1-V3 with ST depression in V4-V6 associated with deep T wave inversion. Chest X-ray revealed dextrocardia with a right-sided aortic knob as well as gastric bubble. Echocardiography revealed left ventricle ejection fraction of 40% with hypokineses correspondent with ischemia in left anterior descending artery (LAD) territories and no significant valve disease. Cardiac catheterization was performed via the right radial artery using mirror-image views and standard Judkins catheters. A 5 French (Fr) angulated pigtail catheter was through the right-sided aortic knob into the left ventricle. The 300 left anterior oblique (LAO) ventriculogram (Figure 1) showed anterior wall hypokinesia and severe hypokises/akineses of the apex and the inferior wall with an ejection fraction of 40%. The ostium of the right coronary artery (RCA) was easily engaged by gentle counterclockwise rotation and slightly withdrawal of a 5 Fr Judkins right 4 cm (JR4) diagnostic catheter in right-anterior-oblique (RAO) and RAO-cranial views showed 100% lesion at mid-RCA segment (Figure 2). The ostium of the left main coronary artery was also cannulated using a 5 Fr Judkins left 4-cm (JL4) diagnostic catheter in a RAO view. The selective left coronary angiogram revealed a>70% tubular stenosis in the middle segment of LAD artery and a patent left circumflex (LCX) artery (Figure 3). Adhoc-PCI to LAD was performed with the use of 5 Fr JL 3.5 guide catheter and a 0.014” balanced middleweight (BMW) guide wire. Two overlapping drug-eluting stents (Xience Prime 2.5x28mm and Promus Element 2.25x12mm) were directly deployed at the site of the lesion in the middle segment of the LAD artery with good angiographic result (Figure 4). The patient experienced an uneventful post-PCI course and was discharged on the following day. He was free of angina on clinical follow-up.

Figure 1 Left ventricle angiogram in left anterior oblique view 30˚ showing mirror image anatomical configuration of the left ventricle in conventional right anterior oblique 30˚ view.

Figure 2 Right coronary artery (RCA) injection in right anterior-oblique view 45˚ showing total occlusion in mid RCA. The anatomy is mirror image to RCA injection in conventional left anterior-oblique projection.

Figure 3 Left coronary angiogram in postero-anterior/cranial 40˚ view showing significant lesion in mid left anterior descending artery (LAD). The anatomy is mirror image to the same view in normal case.

Figure 4 Post angioplasty left coronary angiogram in postero-anterior/cranial injection showing normally flowing vessel. The image is mirror image to conventional poster-anterior/cranial projection for the left coronary system in normal situation.

Dextrocardia refers to the position of the heart in the right side of the chest. It is a rare clinical phenomenon with a reported incidence of 1 in 5,000-30,000.¹ In the absence of other structural heart disease, the life expectancy is usually normal. The association of coronary artery disease (CAD) in these patients is the same as in the general population.⁴ Hence, even elderly patients with this rare anomaly have been subjected to successful percutaneous or surgical intervention of CAD, as reported in literatures.^5,6 The first cardiac catheterization in dextrocardia was reported in 1973,⁷ the first coronary artertery bypass surgery in 1980⁸ and the first percutaneous intervention in dextrocardia performed in 1987.⁹

Presentation of patients with dextrocardia with variant myocardial ischemia symptoms of right-sided chest pain has been previously noted.^10–12 The reason for this atypical presentation is unclear. Situs inversus has been previously shown to be associated with abnormal neural axis development¹³ and this may lead to variant visceral pain presentation. Afferent fibers from the heart traveling along the sympathetic trunks of the neck and thorax may enter the higher thoracic levels (T1 to T4/5) from the right rather than the left side, thus associating with spinal ganglia and spinal cord segments receiving sensory impulses from the right side of the body. This may also explain previous reports of ischemic pain referral down the right shoulder and arm in these patients.^7,14,15 Pain localization from abdominal viscera is also discrepant and suggests that peripheral nerve route transposition occurs in about 50% of cases of situs inversus. Consequently, patients with dextrocardia may present with pain referred to either the left or the right side of the body.¹⁶ Moreyra et al.,⁹ who first reported a case of percutaneous transluminal coronary angioplasty in dextrocardia with situs inversus, found Judkins catheters unhelpful and advocated using multipurpose catheters because their flexible tips allowed for easy manipulation into the coronary ostia. It has since been suggested that the suitability of diagnostic and interventional guide catheters can be predicted by the aortic arch position.^17–19 In our experience, however, even in the presence of right-sided aortic arch, the left Judkins catheter can be used to cannulate the right-sided morphologically left coronary artery. Similarly, the right Judkins catheter manipulated to the mirror of its usual position can cannulate the left-sided morphological RCA. Notably, catheter rotation (torquing) is in the opposite direction of that employed for normal cardiac anatomy. Counterclockwise rotation is, for example, required to engage the left sided RCA with the right Judkins catheter. Successful employment of Judkins catheters has been previously reported in a case of dextroversion (dextrocardia with normally related atria and left-sided aortic arch). This is not surprising as in these patients the coronary artery ostia lay close to their usual positions.²⁰ Consequently, contrary to previous reports, we suggest that the standard performed catheters may be employed in cases of dextrocardia with both right and left-sided aortic arch positions. A double-inversion technique of reversed image acquisition and horizontal inversion of on-screen display has been previously described.²¹ In our case, angiography and intervention were performed without on-screen reversal of the images. It is still necessary, however, to reverse the transverse angulations whilst maintaining the common cranial/caudal sagital tilts. A RAO caudal view, for example, produces a mirror image LAO caudal view. Although the double inversion technique makes the coronary tree appear “normal” with normal orientation, it also artificially reverses the on-screen response of catheters and angioplasty wires to normal manipulation (torquing). Consequently, although it may aid image interpretation, we found this technique unhelpful for PCI.

Trans-radial coronary angiography and angioplasty have emerged as safe, feasible, and effective alternative with similar results to those of the trans-femoral approach with negligible rate of major vascular complications.^22,23 Trans-radial PCI in dextrocardia was first reported in 2007²⁴ and since then there are only 5 reports on transradial intervention in patients with dextrocardia^25–29 out of which one patient underwent the procedure through left radial approach. In all of those reported cases, the operators used 6Fr-system but in our case we used 5Fr system successfully. Honda and his colleagues found that downsizing of the devices used in transradial procedures might attenuate access site-related bleeding or occlusive complications after transradial coronary angiography or PCI.³⁰

In summary, we report to our knowledge the first case of transradial PCI in dextrocardia using 5Fr system. We also report that transradial PCI is effective and safe in dextrocardia as well as it used to be in normal population. Standard Judkins catheters can be effectively used to cannulate right and left coronary arteries using counterclockwise catheter rotations and mirror-image views.
