Case Report Volume 6 Issue 2

Open Reduction and Internal Fixation of an Osteochondral Patellar Fracture in an Eleven Year-Old Girl

António Robalo Correia,1 Nuno Marques Luís,2 Igor Lima Martins,1 ré Lopes Vasques,1 Filipa Gonçalves Pereira,1 Francisco de Brito1

1Department of Orthopaedic Surgery, Hospital Jose Joaquim Fernandes, Portugal
2Department of Orthopaedic Surgery, Cl

Correspondence: Antonio Pedro Robalo Correia, Rua Ilidio Oliveira Guerra n35; 2430-463 Marinha Grande; Portugal, Tel 352000000000

Received: October 21, 2016 | Published: October 21, 2016

Citation: Correia AR, Luís NM, Martins IL, Vasques AL, Pereira FG, et al. (2016) Open Reduction and Internal Fixation of an Osteochondral Patellar Fracture in an Eleven Year-Old Girl. MOJ Orthop Rheumatol 6(2): 00215. DOI: 10.15406/mojor.2016.06.00215

Download PDF

Abstract

Osteochondral patellar fractures in pediatric age can result from acute patellar dislocations (APDs). The purpose of this article is to document and discuss the surgical treatment performed to a young female patient diagnosed with an osteochondral fracture (OCF) of the patella in the first episode of an APD.

We state the first episode of an APD in a 12 year-old girl, who presented with pain, edema and limited extension of the right knee, after a direct knee trauma. She had no predisposing factors regarding patellofemoral instability. This patient was treated at our Orthopaedic Surgery Department and then clinically (Kujala score) and radiographically evaluated, at 12 months of follow-up.

The knee radiograms gave rise to the suspicion of a large inferior osteochondral patellar fragment. Operative treatment was decided and open reduction and internal fixation (ORIF) of the fragment was performed, through a medial parapatellar approach. The fragment dimensions were 24x18mm. The medial structures were addressed and repaired. The patient went through a rehabilitation programme and returned to full activities three months postoperatively. After 12 months of follow-up, there was full range of motion, no redislocation episodes and the Kujala score was 96.

Open reduction and anatomic in situ internal fixation of the osteochondral fragment was mandatory in this case, due to its dimensions and location. We consider this a safe and efficient technique that allows osteosynthesis of the osteochondral fragment; the approach used makes possible the acute repair of the medial structures. There is still no general consensus about whether or not to reconstruct the medial patellofemoral ligament (MPFL) in the context of a primary APD.

KeywordsPrimary acute patellar dislocation; Osteochondral patellar fracture; ORIF; patellofemoral

Abbreviations

APD, Acute Patellar Dislocation, OCF, Osteochondral Fracture, ORIF, Open Reduction Internal Fixation, MPFL, Medial Patellofemoral LigamentED, Emergency Department, ROMRange Of Motion, VMO, Vastus Medialis Obliquous, MRI, Magnetic Resonance Imaging.

Introduction

Acute patellar dislocations (APD) are common in pediatric age and can be associated to osteochondral fractures (OCF) of the patella, the lateral femoral condyle, or both.1,2 According to some works.1,3 the incidence of OCF is underestimated. In fact, osteochondral patella fractures can be easily missed on plain knee radiograms.1,4 making neglected OCF of the patella a possible reason for claims for financial compensation against attending doctors.5 Although APD can occur even in the context of a stable knee, patient-related predisposing factors may contribute to dislocation.6,7 The goal of this article is to document and debate the surgical treatment performed to a patient with an OCF of the patella, in the context of the first episode of an APD, in a previously stable patellofemoral joint.

Case Presentation

11 year-old healthy girl, with no previous symptoms of patellar instability, no known anatomic variations, nor hyperlaxity criteria. She was brought to the emergency department (ED) presenting with pain, edema and limited extension of the right knee, after a direct trauma of the patella- fall from her height, with the knee in flexion. Although she presented in the ED with a reduced patella, the story was compatible with patella dislocation and then reduction with an extension movement, performed by a local caregiver. The knee examination revealed a joint effusion under tension and the arthrocentesis revealed 70mm3 of hematic liquid, with evidence of fat deposits. The tense knee hemarthrosis made us suspect of an OCF.

The knee radiograms revealed a free articular body that we interpreted as a possible osteochondral patella fracture (Figures 1 & 2).

Figures 1 & 2 AP and lateral radiograms: possible large inferior osteochondral patellar fragment, acting as a free articular body.

Due to the fragment characteristics (dimensions and location), surgical treatment was the option. In the same day, the child was operated: a medial parapatellar approach was chosen (Figure 3).

Figure 3 Medial parapatellar approach of the right knee, showing a large void beginning at the inferior pole of the patella, with extension to both facets, mostly the medial one.

The intrarticular fragment was identified, measured (24x18mm), washed and cleaned (Figures 4 & 5).

Figures 4 & 5 Anterior and posterior faces of the osteochondral fragment.

An open reduction and internal fixation with two subchondral 1.7 mm titanium alloy (Ti6A14V) headless screws was performed. Anatomic reduction was intraoperatively confirmed (Figure 6).

Figure 6 Anatomic reduction of the patella, with two 1.7 mm screws, subchondrally inserted.

Since a medial arthrotomy was used, it was possible to suture the medial soft tissues, enhancing patellofemoral stability. The knee was then immobilized with a posterior protective cast for four weeks. After that period, she was immobilized with McConnell tapping and began a staged rehabilitation program: 1) Non-weight bearing exercises to gain range-of-motion (ROM); 2) Iliotibial band and hamstrings stretching; 3) Lateral patellar retinaculum stretching; 4) Gastrocnemius and quadriceps muscles stretching; 5) Quadriceps and vastus medialis obliquous (VMO) strengthening. Three months postoperatively, the patient was asymptomatic, with full ROM and already playing sports; the radiograms showed bone healing (Figures 7 and 8). At twelve months of follow-up, the Kujala score was 96 and there were no redislocation episodes.

Figures 7 & 8 Postoperative radiograms (3 months), showing good placement of the 1.7mm screws and bone healing.

Discussion

There are two main topics deserving discussion, suggested by this clinical case. The first one is about the diagnosis of this condition. In the context of an APD, the diagnosis of an OCF asks for a high degree of clinical suspicion and close look at the radiograms. In the presented case, the clinical data and the radiograms directed us to a possible diagnosis of a patellar OCF. A useful clinical clue was the presence of a tense hemarthrosis with fatty deposits when arthrocentesis was performed. However, it would have been wise to use magnetic resonance imaging (MRI) to enlighten the observed lesion, in what respects to certainty the source of the OCF (the patella), its dimensions and associated chondral alterations.8 Furthermore, MRI is of prime importance to localize possible medial patellofemoral ligament (MPFL) tears, which can be patellar, femoral or multifocal. In young children (aged 9 to 14), the patellar attachment site is the most commonly damaged, occurring a total rupture in more than half of the cases.9 The second topic prone to discussion refers to treatment. Considering the initial step consensual towards surgical treatment, four major questions emerged next: 1) Which approach to use? 2) How to fix the osteochondral fragment? 3) Conservative versus repair versus reconstruction of the medial structures; 4) Which physiotherapy program to adopt postoperatively? Concerning the first question, the medial parapatellar approach used was related to the osteochondral fragment characteristics, whose majority belonged to the medial patellar facet. In this particular case, there was no indication for lateral patellar retinaculum release. About fragment fixation, the articular character of the fracture demanded an anatomic reduction, with absolute stability. The option between fixing and excising the fragment related to the fragment size (24x18mm, amenable to fixation). An otherwise small OCF, if symptomatic, would have been excised.7 Despite representing a last resort procedure, excision combined with microfractures grants satisfactory results, according to some studies.10 We opted for internal fixation with two headless 1.7 mm titanium alloy screws. Other viable option would have been biodegradable implants, but some important side effects have been demonstrated.11 12 In what concerns to the action taken towards the MPFL, arguments for conservative treatment are: this was the first episode of an APD.13 there were no anatomic variations, nor hyperlaxity criteria (MPFL rupture is not the cause, but a consequence of an APD). The arguments for surgical treatment, whether repair or reconstruction, are: since a medial arthrotomy was used, a MPFL repair would be a reasonable procedure; some prospective studies begin to show better long term results for MPFL reconstruction, compared to those observed with conservative treatment.14 As our knowledge about the biomechanical importance of the MPFL evolves - mainly its role against lateral displacement during motion and under high lateral stresses.15 - the more orthopaedic surgeons consider MPFL reconstruction the mainstay of treatment, even in the context of a primary APD.16 Postoperatively, the McConnell tapping method was applied, with the goals of protecting and maintaining / improving the patellofemoral biomechanics.17 In summary, despite paucity of diagnostic imaging exams, a good functional outcome was achieved. We believe that was due to a well-chosen and performed surgical technique and a correct postsurgical rehabilitation programme. Despite all the available evidence and progresses made towards a progressively better treatment for these patients, there is still no universal true about the perfect treatment for patients suffering from primary APD that can comprise all the specter of possible clinical variations.18
