Research Article Volume 3 Issue 1

Giant cell tumors (GCT) around knee- curettage and reconstruction by Ilizarov technique

Bari MM,1 Shahidul Islam,1 NH Shetu,1 Wahidur Rahman,1 Mahfuzer Rahman,1 Mashiur H Munshi,2 Mohammad R Islam Khan2

1Chief Consultant, Bari-Ilizarov Orthopaedic Centre, Visiting and Honored Prof., Russian Ilizarov Scientific Centre, Russia
2National Institute of Traumatology and Orthopaedic Rehabilitation, Bangladesh

Correspondence: Mofakhkharul Bari, Chief Consultant, Bari-Ilizarov Orthopaedic Centre, Visiting and Honored Professor, Russian Ilizarov Scientific Centre, Kurgan, Tel +88 01819 211595

Received: May 16, 2015 | Published: June 26, 2015

Citation: Bari MM, Islam S, Shetu NH, et al. Giant Cell Tumors (GCT) around Knee- Curettage and Reconstruction by Ilizarov Technique. MOJ Orthop Rheumatol. 2015;3(1):239-242. DOI: 10.15406/mojor.2015.03.00079

Download PDF

Abstract

Purpose: To evaluate outcomes of 17 patients who underwent curettage, use of phenol and reconstruction using the llizarov technique for giant cell tumors (GCT) of bone around the knee.
Methods: 12 men and 5 women aged 18 to 45 (mean 26) years underwent intralesional curettage, use of phenol, and reconstruction using the Ilizarov technique for GCT of the proximal tibia (n=14) or distal femur (n=3), 5 of the cases were recurrence. 3, 12 and 2 tumors were classified as grade-I, grade-II and grade-Ill, respectively. One of the grade-III tumors was associated with an extra-articular pathological fracture. Patients underwent intralesional curettage, use of phenol and reconstruction by Ilizarov technique [1,2]. Functional outcome was evaluated using the Musculo skeletal tumor society (MSTS) score.
Results: The mean follow up period was 6 (2.5-10) years. The mean MSTS score was 28.5 out of 15 (Standard deviation, 3; range, 15-30. No patient had malignant transformation.
Conclusion: Intralesional curettage use of phenol and reconstruction with llizarov for GCT of bone achieved good functional outcome and no recurrence rate.

Keywords: Curettage; GCT of bone; Phenol; Ilizarov

Abbreviations

GCT: Giant Cell Tumors; MSTS: Musculo Skeletal Tumor Society; NITOR: National Institute of Traumatology and Orthopaedic Rehabilitation

Introduction

GCT of bone is one of the most common benign bone tumors occurring around the knee in those aged 30 to 45 years. It is locally aggressive and prone to recurrence and malignant transformation [3]. Treatment by curettage, alone has a high risk of recurrence [4,5]. Use of adjuvants (phenol, cement, cryosurgery or a combination of these) is recommended, followed by reconstruction with allograft, autograft, cement or hydroxyapatite. In NITOR (National Institute of Traumatology and Orthopaedic Rehabilitation, Dhaka) and Bari-Ilizarov Orthopaedic Centre, the treatment of GCT of bone has been intralesional curettage followed by the use of phenol and reconstruction using Ilizarov technique [6]. This study evaluated outcome of 17 patients who underwent curettage, use of phenol and reconstruction using the llizarov technique for GCT of bone around the knee.

Materials and Methods

Between January 2005 and January 2013, 12 men and 5 women aged 18 to 45 (mean 26) years underwent intralesional curettage, use of phenol and reconstruction using the Ilizarov technique for GCT of the proximal tibia (n=14) or distal femur (n=3), 5 of the cases were recurrences.

According to Capanacci grading systems [6] 3 tumors were classified as grade-I (with a well-defined margin and intact cortex), 12 were graded-II (with a relatively well defined margin, but no radio opaque rim and the thinned and moderately expanded cortex) and 2 were grade-III (with indistinet borders with cortical destruction). One of the grade-III tumors were associated with an extra articular pathological fracture of the femur (n=1).

Through a large cortical window, the tumors were curetted until normal appearing bone was seen. The cavity was cleaned with pulsatile lavage of 5% phenol and phenol soaked gauge was placed inside the cavity for 3 minutes. Care was taken not to spill the phenol to the surrounding tissues. Phenol was not used in cases with a pathological fracture. The damaged bone was then removed. The gap that is created was filled up with compression distraction method by Ilizarov technique [1,2].

Postoperatively, partial weight bearing crutch walking was started immediately. After 3 days weight bearing was allowed as tolerated and after few days gradual full weight bearing was started. Intravenous Zoledronate (4mg) once monthly was given for 6 months, along with oral supplementation of vitamin D3 (800 1.4) and calcium (1-2 gm) once daily for 6 months.

Functional outcomes were evaluated using the Musculo Skeletal Tumor Society (MSTS) score [7] which involves 6 parameters (pain, function, emotional acceptance, use of walking aids, walking ability, and gait). Scores for each parameter range from 0-5, higher scores indicate better outcome.

Results

The mean follow up period was 6 (2.5-10) years. The mean MSTS score was 28.5 out of 15 (standard deviation, 3' range 15-30). No patient had malignant transformation.

Case illustrations
 (Figures 1-10)

Figure 1: Recurrence of right knee GCT, huge swelling is seen.

Figure 2: 35 years old male recurrence of GCT of tight knee.

Figure 3: Radiographic view of right upper tibia with bone cement soft tissue involvement is seen

Figure 4: Bone cement and intralesional tissue are seen.

Figure 5: After removal the tissues a big cavity is seen in OR.

Figure 6: After 15 days of follow up a defect is seen

Figure 7: 2 rings (above and below) with 4 telescopic rods applied for segmental transportation by 2 olive wires.

Figure 8: Radiographic view after 3 months follow up.

Figure 9: Final radiographic view of upper tibia with full consolidation after 6 months

Figure 10: Clinical result and appearance of the patient after 6 months.

Discussion

Treatment of giant cell tumors around the knee include curettage alone, curettage with adjuvant therapy (liquid Nitrogen, hydrogen peroxide, phenol, bone cement or bone graft) and marginal or wide resection, followed by reconstruction with Ilizarov technique, arthrodesis or mega-prosthetic joint replacement. Intralesional curettage alone has a high recurrence rate of 60% [8], whereas marginal or wide resection is associated with functional disability. Preservation of joint function is an advantage of intralesional curettage compared to wide resection. In our series intralesional curettage and reconstruction with Ilizarov technique achieved a low recurrence rate (2%) and good functional outcome (95.5%). The use of 5% phenol decreases recurrence [9] as phenol causes protein coagulation and necrosis and damages DNA [10].

The risk of neurovascular injury by phenol increases if the posterior periosteum is deficient. The cavity can be reconstructed by new regenerate bone with distraction compression method of Ilizarov technique. The advantage of Ilizarov technique is bone transportation and that reconstruction is permanent. In our series in all the cases bone transportation was done and bone defect was replaced by new regenerate bone.

Conventionally, grade-III lesions are treated with wide resection to prevent local recurrence [10]. The recurrence rates for grade-III lesions after intralesional curettage are reported to range from 4.5% to 52% [11,12].

In our series, only one of the 2 patients with grade-III GCT of bone had a recurrence. The Ilizarov technique appears to be a viable alternative to wide resection. The use of intravenous Zolendronate as an adjuvant specifically targets the osteoclasts and the GCT cells. Biophosphonates reduces tumor size and recurrence rate in GCT of bone [13]. Biophosphonates bind to bone and inhibit bone resorption by osteoclasts [14]. Biophosphonetes not only induce apoptosis of osteoclasts and neoplastic stromal cells, but also possess a direct anti-tumor and anti-angiogenesis activity [15]. Biophosphonetes do not have any adverse effect on osteoblasts or reparative mechanisms of bone [16].



Conclusion

Well intralesional curettage, use of phenol and reconstruction by Ilizarov for GCT of bone achieved good functional outcome and a low recurrence rate. Preservation and bone degeneration by means of distraction osteogenesis constitutes a highly conservative limb saving surgery. Patient with good defects of less than 10 cm, a great deal of preserve healthy tissue and good prognosis are good candidates for these methods.

References

  1. Balaev II (2006) Treatment of tumors of long bones. Safe restorative operation's using Ilizarov apparatus, Kurgan, Russia.
  2. Bari MM (2013) A color atlas of limb lengthening, surgical reconstruction and deformity correction by Ilizarov technique. pp. 310-314.
  3. Eckardt JJ, Grogan TJ (1986) Giant cell tumor of bone. Clin Orthop Relat Res (204): 45-58.
  4. Arbeitsgemeinschaft Knochentumoren, Becker WT, Dohle J, Bernd L, Braun A, et al. (2008) Local recurrence of giant cell tumor of bone after intralesional treatment with and without adjuvant therapy. J Bone Joint Surg Am 90(5): 1060-1067.
  5. Capanacci M, Baldini N, Boriani S, Sudanese A (1987) Giant cell tumor of bone. J Bone Joint Surg Am 69(1): 106-114.
  6. Capanacci M, Cepanna R, Fabbri N, Beltell G (1990) Curettage of giant cell tumor of bone. Reconstruction with subchondral grafts and cement. Chir Organu Mov 75(1 Suppl): 212-213.
  7. Pettersson H, Rydholm A, Persson B (1986) Early radiologic detection of local recurrence after curettage and acrylic cementation of giant cell tumors. Eur J Radiol 6(1): 1-4.
  8. Carrasco CH, Murray JA (1989) Giant cell tumors. Orthop Clin North Am 20(3): 395-405.
  9. Durr HR, Maier M, Jansson V, Baur A, Refior HJ (1999) Phenol an adjuvant for local control in the treatment of giant cell tumor of the bone. Eur J Surg oncol 25(6): 610-618.
  10. Lock W, Lang S, Brand G (1994) Necrotizing effect of phenol on normal tissues and on tumors. A study of postoperative and cadaver specimens. Acta Orthop Scand 65(3): 351-354.
  11. Lackman RD, Hosalkar HS, Ogilive CM, Torbert JT, Fox EJ (2005) Intralesional curettage for grades-II and III giant cell tumors of bone. Clin Orthop Relat Res 438: 123-127.
  12. Mc Donald DJ, Sim FH, Mc Leod RA, Dahlin De (1986) Giant cell tumor of bone. J Bone Joint Surg Am 68(2): 235-242.
  13. Tse LF, Wong KC, Kumta SM, Huang L, Chow TC, et al. (2008) Biphosphonates reduce local recurrence in extremity giant cell tumor of bone; a case control study. Bone 42(1): 68-73.
  14. Rogers MJ, Gordon S, Benford HL, Coxon FP, Luckmen SP, et al. (2000) Cellular and molecular mechanisms of action of biphosphonates. Cancer 88(12 Suppl): 2961-2978.
  15. Neville-Webbe HL, Holen I, Coleman RE (2002) The anti-tumor activity of biphosphonates. Cancer Treat Rev 28(6): 305-319.
  16. Madsen JE, Berg-Larsen T, Kirkeby OJ, Falch JA, Nordsletten L (1998) No adverse effects of clodronate on fracture healing in rats. Acta Orthop Scan 69(5): 532-536.
