Unilateral double testicular arteries surround renal vein

doi:10.15406/mojap.2019.06.00263

MOJ

eISSN: 2471-139X

Anatomy & Physiology

Case Report Volume 6 Issue 5

Unilateral double testicular arteries surround renal vein

Ahmad Tamjidipour, Asghar Rajabzadeh

Verify Captcha

Regret for the inconvenience: we are taking measures to prevent fraudulent form submissions by extractors and page crawlers. Please type the correct Captcha word to see email ID.

Department of Anatomy, Lorestan University of Medical Sciences, Iran

Correspondence: Asghar Rajabzadeh, Department of Anatomy, Lorestan University of Medical Sciences, Faculty of Medicine, Khorramabad, Iran

Received: June 16, 2019 | Published: September 11, 2019

Citation: Tamjidipour A, Rajabzadeh A. Unilateral double testicular arteries surround renal vein. MOJ Anat & Physiol. 2019;6(5):148-149. DOI: 10.15406/mojap.2019.06.00263

Download PDF

Abstract

Normally, male’s testicular arteries are originating from the abdominal aorta. In this case, we noted that testicular artery variations are related to renal and/or aorta arteries. The aim of this presentation was to evaluate the testicular arteries in male’s reproductive system and their contribution with renal function in some disorders. During routine dissection of abdomen’s retroperitoneal region, in a 60-year-old male cadaver, we observed double variant testicular arteries with circle loop around left renal vein. Anatomical variations of testicular and renal vessels must be considered to solve male genital, and/or renal disorders.

Keywords: double testicular arteries, renal vein, artery-vein anastomosis

Introduction

Bilateral testicular arteries (TAs) are the ventral subdivisions of abdominal aorta, mostly separated at the lower starting point of the renal arteries, and obliquely descended on the psoas major muscles. In the retroperitoneal region of abdomen, they run on the superior aperture of pelvis and enter into the spermatic cords in the inguinal canal. Clinical features and the awareness of TAs variants are associated with solving such a comprehensive issue of fertility and varicocele.¹ Mostly some reports showed that variant testicular artery aroused from renal arteries or with double source of origin from aorta, frequently took place on the right side.^2,3 In our case report, we observed double TAs are originated from aorta in addition to testicular (artery)-renal (vein) anastomosis on the left side.

Presentation

In our anatomy department, a 60-year-old male cadaver fixed with formalin was used for the research and educational course. After one year, during routine dissection of posterior abdominal wall (level L1-L2), we noticed that an artery with double origin arised from the left side of aorta (Figure 1). Two arteries were joined together under the renal vein, after forming loop around it. In fact, it seems that ascending branch of lower testicular artery was linked to renal vein (Figure 1). The upper testicular artery passes posteriorly to the renal vein and joins to the lower artery (Figure 2). This position of TAs displays an abnormal arterial pressure on renal vein. In this case, a significant point was hypertension of the left renal vein compared to the same vein on the right side. In the similar condition, this pressure can affect drainage of renal venous, and renal hypertension.¹ Recorded figures of vessels morphology was obtained by high quality camera.

Figure 1 LRV, left renal vein; bold arrow, lower originated left testicular artery from aorta; thin arrow, descending part of highest testicular artery after rotated behind left renal vein; short arrow, ascending part of lower testicular artery that anastomosis with left renal vein.

Figure 2 LK, left Kidney; bold arrow, lower originated left testicular artery from aorta; thin arrow, descending part of highest testicular artery after rotated behind left renal vein; short arrow, ascending part of Lower testicular artery that anastomosis with left renal vein.

Discussion

The variation of male’s testicular arteries is may be considering due to important correlation with clinical complications, especially fertility or surgical performance in the retroperitoneal region related to kidneys. In this setting, anatomical information can respond to the most clinical questions in the male reproductive problems, as well as, nephrectomy and renal transplantation.⁴ Abnormal pressure of testicular vessels on renal vein may be effect on function, and choosing suitable surgery protocol of kidneys.⁵ The presence of some variance is critical when they reduce the blood supply to sensitivity organs as testis or kidneys. Although there are several reports on variant testicular arteries, most of them showed unilateral or bilateral double arteries.¹ In this report, we also showed a variant case concerning to testicular artery that unusually the renal vein was surrounded by their branches, and likely abnormal anastomosis among artery and vein. Since 1928, reports of cadaver and surgical cases showed that variant TAs has been occurred on both right and left sides, with high contribution of right testicular artery.^6–9 Also this is possible that these arteries originate from suprarenal artery which it only reported in 2012.¹⁰ Conclusively, our report presents a unique case of TAs variants concerning their source of origin and exclusively pressure from double testicular arteries onto hyper tensioned renal vein. Supplementary examinations such as radiological approaches, Doppler ultrasound or arteriography may be contributing to appropriate understanding of the gonadal and/or retroperitoneal vessels.

Conclusion

Based on origination of testicular artery and its routes at the anatomical position, this point can be express that information of these vessels and their variations will make the best strategy of diagnosis in the male’s genital disorders.
