Persistent left superior vena cava and its clinical implications: case report and literature review

José Aderval Aragão,1,3 Iapunira Catarina Sant’Anna Aragão,2 Felipe Matheus Sant’Anna Aragão,2 Paôla Cardoso,2 Fernanda Pimentel Cavaliere de Barros,2 Rafael dos Santos Reis,2 Marcos Guimarães de Souza Cunha,2 Elomar Rezende Moura,3 Francisco Prado Reis3

1Morphology Department, Federal University of Sergipe (UFS), Brazil
2Medical School, University Center of Volta Redonda (UNIFOA), Brazil
3Medical School of Tiradentes University (UNIT), Brazil

Correspondence: José Aderval Aragão, Federal University of Sergipe, Marechal Rondon Avenue, São Cristóvão, Sergipe, Brazil, Tel 55 79 991916767

Received: August 18, 2020 | Published: September 11, 2020

Citation: Aragão JA, Aragão ICSA, Aragão FMSA, et al. Persistent left superior vena cava and its clinical implications: case report and literature review. MOJ Anat Physiol. 2020;7(5):130-132. DOI: 10.15406/mojap.2020.07.00303

Download PDF

Abstract

The persistent left superior vena cava venous anomaly is the most common congenital malformation of the thoracic venous system with an estimated prevalence of 0.3 to 0.5%. After dissection of a 30-week-old male fetus, was observed a persistent left superior vena cava that drained into the left atrium. Understanding this anomaly is crucial, given the widespread use of invasive cardiac and electrophysiological procedures.

Keywords: anatomical variation, left superior vena cava, left atrium, congenital heart disease, fetal echocardiography, embryology

Abbreviations

AA, aortic arch; BA, brachiocephalic artery; LA, left atrium; LCCA, left common carotid artery; LIJV, left internal jugular vein; LIPV, left inferior pulmonary vein; LL, left lung; LSA, left subclavian artery; LSV, left subclavian vein; LSVC, left superior vena cava; LUPV, left upper pulmonary vein; LV, left ventricle; PAT, pulmonary artery trunk; RA, right atrium; RCCA, right common carotid artery; RIJV, right internal jugular vein; RL, right lung; RSA, right subclavian artery; RSV, right subclavian vein; RSVC, right superior vena cava; RV, right ventricle; PLSVC, persistent left superior vena cava

Introduction

Persistent left superior vena cava (PLSVC) is the most common systemic venous return anomaly, with an estimated prevalence of 0.3-0.5% in the general population, of 4-8% in patients with congenital heart disease1–4 and 0.9% in the fetal population.5

The origin of the PLSVC is not yet completely clear, it is believed to be the result of an intrauterine failure of the development of the left anterior cardinal vein, resulting in the bilateral presence of superior vena cava,6 but in the last years the prenatal diagnosis of PLSVC has been done based on an abnormal view of three vessels in the upper mediastinum, showing a supernumerary vessel to the left of the pulmonary trunk and arterial duct.7

Although there are many divergences regarding the true prevalence, the PLSVC does not have major clinical impacts, as systemic venous blood continues to return to the right atrium through the coronary sinus, and there is usually a normal right superior vena cava.8,9

The recognition of PLSVC is of great importance for anatomists, clinicians and surgeons, especially in the implantation of long-term central venous catheter.10–12 Thus, the present article aimed to report a finding of a persistent left superior vena cava in a human fetus corpse and to review the literature.

Case report

During a routine dissection at the anatomy laboratory of the Federal University of Sergipe, São Cristóvão, SE, Brazil, it was observed in a male human fetus, with an estimated age of 30 weeks (hallux-calcaneus measurement), a persistent left superior vena cava (Figure 1). The left superior vena cava was lateral to the left common carotid artery and anterior to the left subclavian artery, had a caudal direction, passed lateral to the pulmonary artery trunk and aortic arch, ventral to the left lung hilum and flowed into the left atrium along with the pulmonary veins (Figure 2). The right superior vena cava also followed a descending path along the right upper part of the mediastinum and ended into the right atrium.

Figure 1 Persistent left superior vena cava.
AA, aortic arch; BA, brachiocephalic artery; LCCA, left common carotid artery; LIJV, left internal jugular vein; LL, left lung; LSA, left subclavian artery; LSV, left subclavian vein; LSVC, left superior vena cava; PAT, pulmonary artery trunk; RA, right atrium; RCCA, right common carotid artery; RIJV, right internal jugular vein; RL, right lung; RSA, right subclavian artery; RSV, right subclavian vein; RSVC, right superior vena cava; RV, right ventricle.

Figure 2 Persistent left superior vena cava draining directly into the left atrium.
AA, aortic arch; BA, brachiocephalic artery; LA, left atrium; LCCA, left common carotid artery; LIJV, left internal jugular vein; LIPV, left inferior pulmonary vein; LL, left lung; LSA, left subclavian artery; LSV, left subclavian vein; LSVC, left superior vena cava; LUPV, left upper pulmonary vein; LV, left ventricle; RCCA, right common carotid artery; RIJV, right internal jugular vein; RL, right lung; RSV, right subclavian vein; RSVC, right superior vena cava.

Discussion

The persistence of the left superior vena cava has been observed in the general population, being the most common abnormality of intrathoracic vessels,8 caused by variations in the embryological development of the thoracic venous system.13 This abnormal vein originates from the left anterior cardinal and common cardinal veins, and normally flows into the right atrium through the coronary sinus.14,15

The anomalous systemic venous connection is a rare abnormality, which can be completely asymptomatic, as the persistent left superior vena cava drains in more than 90% into the coronary sinus, but can also drain directly into the left atrium in just 0.03% of the population, and in this case causing cyanosis.16,17 In our case, the persistent left superior vena cava drained directly into the left atrium.

Drainage to the left atrium is often associated with atrial septal defect and can be seen in the absence of a coronary sinus,18 with the coronary sinus orifice persisting as an interatrial communication.19 The persistent left superior vena cava is associated with varied cardiac structural abnormalities, including bicuspid aortic valve, atrial septal defect, coronary sinus ostia atresia and aortic coarctation.3

In most cases, these variations are clinically silent and can be discovered accidentally in radiological studies done for other reasons. However, they should be kept in mind when these patients are candidates for insertion of central venous catheters or cardiothoracic surgery.20,21

In patients with known congenital anomalies of the superior vena cava undergoing insertion of central venous catheter insertion, several important aspects must be considered for a safe and effective procedure: accurate preoperative planning with image description of the anomalies of the veins, careful selection of the most appropriate vascular access and the use of ultrasound and fluoroscopic guidance by qualified professionals,22 which is of great importance in all invasive and non-invasive procedures, such as transthoracic echocardiography and cardiac tomography.

Conclusion

Persistent left superior vena cava is a rare abnormality of systemic venous return often associated with other congenital cardiac malformations and physicians should be aware of such anomaly and its clinical implications in order to avoid possible complications.

Acknowledgments

None.

Conflicts of interest

The authors declare there are no conflicts of interest.

References

  1. Steinberg I, Dubilier W Jr, Lukas DS. Persistence of left superior vena cava. Dis Chest. 1953;24(5):479–488.
  2. Fraser RS, Dvorkin J, Rossall RE, et al. Left superior vena cava: a review of associated congenital heart lesions, catheterization data and roentgenologic findings. Am J Med. 1961;31:711–716.
  3. Nsah EN, Moore GW, Hutchins GM. Pathogenesis of persistent left superior vena cava with a coronary sinus connection. PediatrPathol. 1991;11(2):261–269.
  4. Parikh SR, Prasad K, Iyer RN, et al. Prospective angiographic study of the abnormalities of systemic venous connections in congenital and acquired heart disease. CathetCardiovascDiagn. 1996;38(4):379–386.
  5. Galindo A, Gutiérrez-Larraya F, Escribano D, et al. Clinical significance of persistent left superior vena cava diagnosed in fetal life. Ultrasound Obstet Gynecol. 2007;30(2):152–161.
  6. Gustapane S, Leombroni M, Khalil A, et al. Systematic review and meta-analysis of persistent left superior vena cava on prenatal ultrasound: associated anomalies, diagnostic accuracy and postnatal outcome. Ultrasound Obstet Gynecol. 2016;48(6):701–708.
  7. Yoo SJ, Lee YH, Kim ES, et al. Three- vessel view of the fetal upper mediastinum: an easy means of detecting abnormalities of the ventricular outflow tracts and great arteries during obstetric screening. Ultrasound Obstet Gynecol. 1997;9(3):173–182.
  8. Sarodia BD, Stoller JK. Persistent left superior vena cava: Case report and literature review. Respir Care. 2000;45(4):411–416.
  9. Pahwa R, Kumar A. Persistent left superior vena cava: an intensivist's experience and review of the literature. South Med J. 2003;96(5):528–529.
  10. Konstantinou EA, MariolisSapsakos TD, Katsoulas TA, et al. Persistent left superior vena cava leads to catheter malposition during PICC Port placement. J Vasc Access. 2016;17(2):e29–e31.
  11. Zhou Q, Murthy S, Pattison A, et al. Central venous access through a persistent left superior vena cava: a case series. J Vasc Access. 2016;17(5):e143–e147.
  12. Ricciardi B, Ricciardi CA, Lacquaniti A, et al. Persistent left superior vena cava and partially left inferior vena cava: a case report of a dangerous central venous catheterization. J Vasc Access. 2017;18(5):e66–e69.
  13. Granata A, Andrulli S, Fiorini F, et al. Persistent left superior vena cava: what the interventional nephrologist needs to know. J VascAccess. 2009;10(3):207–211.
  14. Jorquera JC, Gimenez-Salinas LK. Persistent left superior vena cava: Clinical significance. AnPediatr (Barc). 2016;85(2):110–111.
  15. Bisoyi S, Jagannathan U, Dash AK, et al. Isolated persistent left superior vena cava: A case report and its clinical implications. AnnCard Anaesth. 2017;20(1):104–107.
  16. Miraldi F, Carbone I, Ascarelli A, et al. Double superior vena cava: right connected to left atrium and left to coronary sinus. Int JCardiol. 2009;131(2):e78–e80.
  17. Freeman AM, Fenster BE, Weinberger HD, et al. Hypoxia caused by persistent left superior vena cava connecting to the left atrium a rare clinical entity. Tex Heart Inst J. 2012;39(5):662–664.
  18. Raghib G, Ruttenberg HD, Anderson RC, et al. Termination of left superior vena cava in left atrium, atrial septal defect, and absence of coronary sinus; a developmental complex. Circulation. 1965;31:906–918.
  19. Biffi M, Boriani G, Frabetti L, et al. Left superior vena cava persistence in patients undergoing pacemaker or cardioverter-defibrillator implantation: a 10-year experience. Chest. 2001;120(1):139–144.
  20. Singh B, Ramsaroop L, Maharaj J, et al. Case of double superior vena cava. Clin Anat. 2005;18(5):366–369.
  21. Chen SY, Wang XD, Yang TZ, et al. Fetal Persistent Left Superior Vena Cava with Trisomy 21: A Case Report and Literature Review. PediatrNeonatol. 2016;57(3):252–255.
  22. Rossi UG, Rigamonti P, Torcia P, et al. Congenital anomalies of superior vena cava and their implications in central venous catheterization. J Vasc Access. 2015;16(4):265–268.
