Adult grisel’s syndrome: report of a rare case

doi:10.15406/ipmrj.2020.05.00221

eISSN: 2574-9838

International Physical Medicine & Rehabilitation Journal

Clinical Paper Volume 5 Issue 1

Adult grisel’s syndrome: report of a rare case

Alfredo Carvalho,

Verify Captcha

Regret for the inconvenience: we are taking measures to prevent fraudulent form submissions by extractors and page crawlers. Please type the correct Captcha word to see email ID.

André Pinho, Francisco Serdoura, Vitorino Veludo

Orthopedics Service, Centro Hospitalar, São João, Portuga

Correspondence: Alfredo Carvalho, Orthopedics Service, Centro Hospitalar, São João, Portugal

Received: December 13, 2019 | Published: January 6, 2020

Citation: Carvalho A, Pinho A, Serdoura F, et al. Adult grisel’s syndrome: report of a rare case. Int Phys Med Rehab J. 2020;5(1):1?3 . DOI: 10.15406/ipmrj.2020.05.00221

Download PDF

Abstract

Grisel’s Syndrome consists of an atlantoaxial subluxation due to laxity associated with ligament inflammation, usually after infectious processes of the head and neck. It is an extremely rare disease in adults and it’s diagnosis implies a high level of suspicion. Because of its rarity, adult treatment is not completely established. The authors aim to present the case of a 27-year-old patient surgically treated with atlantoaxial arthrodesis by the Wright technique, with a good result at 5 years of follow-up.

Keywords: grisel syndrome, atlanto-axial instability, atlanto-axial arthrodesis

Introduction

Grisel's syndrome is an atlanto-axial instability resulting from ligament laxity caused by inflammation due to head and neck infections, and was described in 1930 by a French Otorhinolaryngologist.¹ It is a typical condition of pediatric patients, with only 14 cases described in adult age.² The main symptom is neck pain, which can be associated with cervical instability, and neurological symptoms due to spinal cord or root compression, which can ultimately lead to the death.² The functional status of the patient can be followed with the Neck Disability Index (NDI), wich is a modification of the Oswestry Low Back Pain Disability Index, a patient-completed, condition-specific functional status questionnaire with 10 items including pain, personal care, lifting, reading, headaches, concentration, work, driving, sleeping and recreation.³

Imaging studies show an increase in Atlanto-Dens Interval (ADI), with an increase in this distance on dynamic radiographs showing atlantoaxial instability, as well as inflammatory changes in perivertebral soft tissues on magnetic resonance imaging.⁴

Contrary to pediatric cases, where conservative treatment is usually effective, C1-C2 surgical stabilization may be necessary in adulthood, although the paucity of cases described in this age group does not aloud strong recommendations.⁵

The authors present a case of adult Grisel's Syndrome, surgically treated with posterior atlanto-axial arthrodesis, using the Wright technique, which consists of atlanto-axial fixation using C1 lateral mass screws, connected with rods to C2 trans-laminar screws⁶ with good clinical and imaging results at 3 years of follow-up.

Clinical case

A 27-year-old male patient with no relevant medical or surgical history and working in the military army, was observed in an Orthopedics consultation, referred from primary health care for complaints of neck pain, without irradiation to the upper limbs, associated with limitation of mobility, especially in sagittal plane movements, with 4 months of evolution (Neck Disability Index (NDI) of 26). The patient denied a history of trauma, but reported upper respiratory infection (pharyngitis) one month before the onset of cervical pain. Physical examination revealed decreased cervical mobility, without other major findings. The diagnostic study began with two-plane cervical radiography (Figure 1), with an approximate ADI value of 10.5 mm, as well as dynamic radiographs (Figure 2), which demonstrated C1-C2 dynamic instability (ADI of 10.9 and 9.8 mm respectively). The CT study confirmed atlanto-axial sub dislocation and excluded the presence of fractures or facet subluxations (Figure 3). The study was complemented by magnetic resonance imaging, which confirmed atlanto-axial sub dislocation, associated with inflammation and thickening of the paravertebral soft tissues, with transverse ligament incompetence (Figure 4 - magnetic resonance imaging). Due to the decreased mobility of the upper cervical spine, the possibility of Meningitis was raised. Blood analytical study showed marginal elevation of C-Reactive Protein (28 mg/L), thus, the hypothesis of Grisel's Syndrome was placed. The patient was initially treated with the use of a Minerva cervical collar and broad-spectrum empirical antibiotic therapy with Ceftriaxone for 6 weeks, but after this period, there was unfavorable clinical evolution, with worsening of cervical pain and functional status (NDI of 30). Surgical treatment was therefore elected, through posterior atlanto-axial fixation, which is in accordance with other cases published in the literature.²The surgery was uneventful and the patient had a favorable clinical course, with significant improvement in neck pain and joint mobility, with an improvement in the NDI from 30 to 5. Radio graphically, a reduction in atlanto-axial subluxation was confirmed (Figure 5), which remained stable until 5 years of follow-up. There were no late complications and the patient resumed his normal activities.

Figure 1 Initial radiografic study.

Figure 2 Dynamic study with C1-C2 instability.

Figure 3 TC image with C1-C2 dislocation.

Figure 4 – Magnetic Ressonance image showing C1-C2 inflamatory tissue.

Figure 5 Radiografic result 5 years after surgery.

Discussion and conclusion

Grisel's syndrome is a typical pediatric entity described in the early twentieth century, and since then only 14 cases in adulthood have been described, which attests to the rarity of the case.² This disease may result from different types of head and neck infections, such as pharyngitis, tonsillitis, otitis, among others, or as a complication of diagnostic or surgical procedures, with biopsy and tonsillectomies.⁷ Diagnosis is often hampered by the mismatch between infection and cervical symptoms and the absence of findings in the diagnostic tests at an early stage, so this is a diagnosis of exclusion.⁸ The pathophysiology of Grisel Syndrome is not completely established, and there are different theories: response to muscle spasm due to inflammation; decalcification of the anterior arch of the atlas resulting from vascular hyperemia caused by the infectious process; previous atlantoaxial laxity aggravated by inflammatory mediators that reach the zone through the pharyngovertebral plexus.⁹

At pediatric age there is usually a positive response to conservative treatment with immobilization and antibiotic therapy. However, treatment in adults often requires surgery, as conservative treatment is associated with bad clinical results.²

There are a number of atlanto-axial surgical stabilization techniques, such as Brooks sub-laminar wiring, Magerl trans-articular screw, and Harms C1 lateral mass – C2 pedicle screw technique. The technique described by Wright in 2004 is technically simpler and with a lower risk of vascular or nerve injury compared to the previous ones, presenting overlapping biomechanical resistance.^6,10,11

In conclusion, adult Grisel's Syndrome is an extremely rare entity whose diagnosis may be delayed by the time lapse between the infectious event and the cervical symptoms. In this age group, surgical treatment is often required, but there is a lack of large sample studies to make strong recommendations regarding treatment in the adult subset of patients.
